Harman Kardon AVR 3700 Manual

SPECIFICATIONS
AVR 3700
What’s included:
• 1 AVR 3700 A/V receiver
• Backlit main remote control
with batteries
• Zone II remote with batteries
• Microphone for EzSet/EQ room-
correction system
• 1 Detachable IEC power cord
• 1 Quick Start Guide
• 1 AM loop antenna
• 1 FM antenna
Audio Section
• Stereo mode continuous average power: 125 watts/ch, 20Hz – 20kHz,
<0.07% THD, both channels driven @ 8 ohms, 6-ohm certied
• Multichannel power: 125 watts/ch, 20Hz – 20kHz, <0.07% THD,
two channels driven @ 8 ohms, 6-ohm certied
• Bandwidth @ 1W (+0dB/–3dB): 10Hz – 130kHz
• Input sensitivity/impedance (line-in): 200mV/47k ohms
• Signal-to-noise ratio (IHF-A): 100dB
• Adjacent channel separation
Dolby Pro Logic
®
I/II: 40dB
Dolby Digital: 55dB
DTS: 55dB
High instantaneous current capability (HCC): ±45 amps
Transient intermodulation distortion (TIM): Unmeasurable
Slew rate: 40V/μsec
FM Tuner Section
• Frequency range: 87.5MHz–108.0MHz
• Usable sensitivity (IHF): 1.3μV/13.2dBf
• Signal-to-noise ratio (mono/stereo): 70dB/68dB
• Distortion (mono/stereo): 0.2%/0.3%
• Stereo separation: 40dB @ 1kHz
• Selectivity (±400kHz): 70dB
• Image rejection: 80dB
• IF rejection: 90dB
AM Tuner Section
• Frequency range: 520kHz – 1,720kHz
• Signal-to-noise ratio: 45dB
• Usable sensitivity (loop): 500μV
• Distortion (1kHz): 50%, mod 0.8%
• Selectivity (±10kHz): 30dB
Video Section
• Television format: NTSC
• Input level/impedance: 1Vp-p/75 ohms
• Output level/impedance: 1Vp-p/75 ohms
• Video frequency response (composite video): 10Hz – 8MHz (–3dB)
• HDMI: 3D, Audio Return Channel, CEC and Deep Color
General
• Power requirement: AC 120V/60Hz
• Power consumption: 120W idle; 1,405W maximum (7 channels driven)
• Dimensions (W x H x D): 17-5/16" x 6-1/2" x 15"
(440mm x 165mm x 382mm)
• Weight: 17.6 lb (8kg)
© 2012 HARMAN International Industries, Incorporated. All rights reserved.
Harman Kardon and Logic 7 are trademarks of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. The “beautiful/sound” logo, EzSet/EQ and the EzSet/EQ logo are trademarks of HARMAN International Industries, Incorporated. AirPlay, the AirPlay logo, Apple, the Apple App Store logo, iPad,
iPhone, iPod and the “Made for iPod, iPhone and iPad” logo are trademarks of Apple Inc., registered in the U.S. and other countries. “Made for iPod,” “Made for iPhone” and “Made for iPad” mean that an electronic accessory has been designed to connect specically to iPod, iPhone and iPad, respectively, and has been certied by the developer
to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone or iPad may affect wireless performance. Android and the “Google play” logo are trademarks of Google Inc. Use of this trademark
is subject to Google Permissions. DLNA Certied and the “DLNA Certied” logo are registered trademarks of the Digital Living Network Alliance. Dolby, Pro Logic, and the double-D symbol are registered trademarks of Dolby Laboratories. DTS is a registered trademark of DTS, Inc. DTS-HD Master Audio and the DTS-HD Master Audio logo are
trademarks of DTS, Inc. HDMI and its logo are registered trademarks of HDMI Licensing, LLC in the United States and/or other countries. The USB logo is a trademark of the USB Implementers Forum, Inc. The “vTuner” logo is a trademark of Nothing Else Matters Software, Ltd. Wi-Fi and the Wi-Fi CERTIFIED logo are registered trademarks of the
Wi-Fi Alliance. All other marks are the property of their respective owners. Features, specications and appearance are subject to change without notice.
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.harmankardon.com
• 125 watts per channel
• Eight HDMI inputs with 3D and Audio Return Channel
including one on the front panel, and two HDMI outputs
• 7.2-channel surround sound
• Dolby TrueHD and DTS-HD Master Audio decoding
• Multizone functionality
• Built-in Wi-Fi and AirPlay audio streaming
• DLNA Certied
®
1.5 connectivity
• High-denition user interface
• 4K video pass-through and scaling
• Full preamp outputs for use with external power ampliers
• Complete Zone 2 audio system with remote control
• EzSet/EQ
™
technology maximizes sonic performance
• Free downloadable control applications for smartphones
and tablets with iOS software and Android application

Harman Kardon AVR 3700 Specifications

Audio Specifications

stereo mode continuous average power	125 watts/ch, 20Hz – 20kHz, <0.07% THD, both channels driven @ 8 ohms, 6-ohm certified
multichannel power	125 watts/ch, 20Hz – 20kHz, <0.07% THD, two channels driven @ 8 ohms, 6-ohm certified
input sensitivity/impedance (line-in)	200mV/47k ohms

Video Specifications

television format	NTSC
video frequency response (composite video)	10Hz – 8MHz (–3dB)
input level/impedance	1Vp-p/75 ohms

Power

power requirement	AC 120V/60Hz
power consumption	120W idle; 1, 405W maximum (7 channels driven)
high instantaneous current capability (HCC)	±45 amps

Weight and Dimensions

dimensions (W x H x D)	17-5/16" x 6-1/2" x 15" (440mm x 165mm x 382mm)
weight	17.6 lb (8kg)
