Harman Kardon AVR 505 User Manual

10/10
Pos Part number 1st part name 2nd part name
IC84 HVI74ACT04MTR I.C , HEX
IC85 HVIRH5VT18C I.C , RESET
IC86 HVINJM4556AL I.C NJM4556AL
IC88 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
JK81 CJJ4M041Y JACK , BOARD (COAX)
JK82 HJSTORX179L MODULE , OPTICAL(RX) TORX179L
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE)
JK85 CJJ9M003Z JACK , S-VIDEO
JK86 CJJ4S023Y JACK , BOARD
JW82 CWZAVR2550JW82 WIRE , ASS'Y
JW84 CWE8202110RV WIRE, ASS'Y
JW85 CWE8202070AA WIRE ASS'Y
SW01 CSH1A008ZV SW , PUSH (MOMS)
VR71 CVV2X05M104Z RES , VARIABLE(BALANCE) RK14128030214Y
VR72 CVV2X07C104Z RES , VARIABLE(TONE) RK14128030214C
VR73 CVV2X07C104Z RES , VARIABLE(TONE) RK14128030214C
VR74 HSR2A026Z VR , ENCODER
X701 HOX05000E160C CRYSTAL
X702 HOX04332E200C CRYSTAL
X703 HOX10000E220C CRYSTAL
1/11
Pos Part number 1st part name 2nd part name
COP11579E MAIN PCB ASS'Y
C501 HCEA1VH100T CAP , ELECT 10UF 35V
C502 HCEA1VH100T CAP , ELECT 10UF 35V
C503 HCEA1VH100T CAP , ELECT 10UF 35V
C504 HCEA1VH100T CAP , ELECT 10UF 35V
C505 HCEA1VH100T CAP , ELECT 10UF 35V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C507 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C508 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C510 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C561 HCEA1CH101T CAP , ELECT 100UF 16V
C562 HCEA1CH101T CAP , ELECT 100UF 16V
C563 HCEA1CH101T CAP , ELECT 100UF 16V
C564 HCEA1CH101T CAP , ELECT 100UF 16V
C565 HCEA1CH101T CAP , ELECT 100UF 16V
C566 HCEA1CH101T CAP , ELECT 100UF 16V
C567 HCEA1CH101T CAP , ELECT 100UF 16V
C568 HCEA1CH101T CAP , ELECT 100UF 16V
C569 HCEA1CH101T CAP , ELECT 100UF 16V
C570 HCEA1CH101T CAP , ELECT 100UF 16V
AVR130FRONT BD
AVR130 MAIN BD
