Harman Kardon AVR 505 User Manual

4/10
Pos Part number 1st part name 2nd part name
C900 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
D724 HVD1SS133MT DIODE 1SS133T-77
D728 HVD1SS133MT DIODE 1SS133T-77
D729 HVD1SS133MT DIODE 1SS133T-77
D730 HVD1SS133MT DIODE 1SS133T-77
D761 HVD1SS133MT DIODE 1SS133T-77
D774 HVD1SS133MT DIODE 1SS133T-77
D775 HVD1SS133MT DIODE 1SS133T-77
D776 KVD1N4003ST DIODE 1N4003
D777 HVD1SS133MT DIODE 1SS133T-77
D778 KVD1N4003ST DIODE 1N4003
D779 HVD1SS133MT DIODE 1SS133T-77
D783 HVD1SS133MT DIODE 1SS133T-77
D784 HVD1SS133MT DIODE 1SS133T-77
D785 HVD1SS133MT DIODE 1SS133T-77
D786 HVDMTZJ5.6BT DIODE , ZENER
D787 HVDMTZJ5.6BT DIODE , ZENER
IC87 HVIRE5VL28CATZ IC , RESET
L702 HLQ02C100KT COIL , AXAIL
Q701 HVTKRC107MT T.R KRC107M
Q702 HVTKRC107MT T.R KRC107M
Q703 HVTKRC107MT T.R KRC107M
Q705 HVTKRC107MT T.R KRC107M
Q706 HVTKRC107MT T.R KRC107M
Q722 HVTKRA107MT T.R KRA107M
Q724 HVTKRC107MT T.R KRC107M
Q725 HVTKRC107MT T.R KRC107M
Q726 HVTKRC107MT T.R KRC107M
Q727 HVTKRC107MT T.R KRC107M
Q728 HVTKRC107MT T.R KRC107M
Q729 HVTKRC107MT T.R KRC107M
Q734 HVTKTC2874BT T.R , MUTE KTC2874B
Q735 HVTKTC2874BT T.R , MUTE KTC2874B
Q736 HVTKTC2874BT T.R , MUTE KTC2874B
Q737 HVTKTC2874BT T.R , MUTE KTC2874B
Q738 HVTKRC107MT T.R KRC107M
Q739 HVTKTA1271YT T.R KTA1271Y
Q743 HVTKRA107MT T.R KRA107M
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R702 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R707 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
AVR130 FRONT BD
