AVR 7000
AUDIO/VIDEO RECEIVER WITH
DOLBY* DIGITAL AND DTS
®
Specifications
•
Audio Section – Continuous
Average Power (FTC): (Stereo
Mode): 110 watts per channel
into 8 ohms @ 20Hz – 20kHz,
<0.07% THD, both channels driven;
(Five-Channel Surround Mode):
100 watts per channel into
8 ohms @ 20Hz – 20kHz,
<0.07% THD, all channels driven;
High Instantaneous Current
Capability (HCC): ±75 amps
• Tuner – Usable Sensitivity:
IHF 1.3µV/13.2dBf; THD at 1kHz
with 100% Modulation: (Mono)
0.2%, (Stereo) 0.3%; FM Adjacent
Channel Selectivity: ±400kHz,
65dB; Ultimate (Maximum) S/N
Ratio (Measured at 1mV RF Input
Level): (Mono) 70dB, (Stereo) 68dB
• General – Dimensions (H x W x D):
7-5/8" x 17-5/16" x 20-7/16"
(193mm x 440mm x 519mm);
Weight: 49 lb (22.3kg)
[NOTE: Depth measurement includes
knobs, buttons and terminal connections;
height measurement includes feet and
chassis.] All features and specifications
are subject to change without notice.
Features
100W x 5 Into 8 Ohms,
20Hz – 20kHz at <0.07%
THD, With All Channels Driven
Simultaneously • High-Current
(±75 Amps), Ultrawide-Bandwidth
(10Hz – 100kHz) Amplifier Design
Effortlessly Powers the Most
Dynamic Digital Sources • Dual,
Matched Pairs of Discrete Output
Devices for Each Channel • Massive
Torroidal Power Transformer • Dual
Amplifier Power Supplies, One
for Drivers and One for Outputs •
Dolby Digital and DTS Surround
Sound Processing Using Advanced
Crystal
®
DSP Engine • Logic 7
Cinema and Music Surround Sound
Processing for Superior Soundstage
Imaging and Playback of Both
Surround Sound and Stereo
Recordings • VMAx Virtual
Surround Sound Provides Home
Theater Experience Using Only
Two Loudspeakers • HDCD
Decoding for More Realistic
Reproduction of HDCD Compact
Discs and Enhanced Playback of
Non-HDCD Discs • Audiophile-
Grade, 96kHz/24-Bit AKM Output
DACs • 6-Channel Direct Inputs
for Use With External Surround
Decoders • Preamp Outputs
and Main Amp Inputs for Use
With External Equalizers or Power
Amplifiers • FM Stereo/FM/AM
Tuner With 30 Presets and
Direct-Access Tuning • Four
Audio Inputs and Five A/V Inputs,
Including S-Video Inputs and
Outputs • Component Video
Inputs and Outputs • Four Digital
Inputs (Two Coaxial, Two Optical)
and Two Digital Outputs • (One
Coaxial, One Optical) • Front-Panel
Play or Record Jacks, Including
Composite Video, S-Video,
L/R Audio • Advanced On-Screen
Menu System for Easy Setup
and Operation • Programmable
Power-Up Volume Level •
Multiroom/Multisource System
for Audio and Video Allows Users
in Separate Rooms to Listen to
Different Sources Simultaneously;
Includes Separate Remote Control
for Multiroom Operation • Eight-
Device, Programmable, Backlit
Universal Remote With Learning
Capability
*Trademark of Dolby Laboratories. DTS is a registered trademark of Digital Theater Systems, Inc. Crystal is a registered trademark of Cirrus Logic Corp. Logic 7 is a registered trademark of Lexicon, Inc.,
a Harman International Company. VMAx is a registered trademark of Harman International Industries, Inc., and is an implementation of Cooper Bauck Transaural Stereo under patent license. , HDCD
®
,
High Definition Compatible Digital
®
and Pacific Microsonics™ are either registered trademarks or trademarks of Pacific Microsonics, Inc., in the United States and/or other countries. Harman Kardon
is a registered trademark, and Power for the Digital Revolution is a trademark, of Harman Kardon, Inc. Part No.: AVR7000PI2/01
250 Crossways Park Drive
Woodbury, NY 11797
800-422-8027 FAX 516-682-3523
www.harmankardon.com
