• Optical Digital Inputs: Connect the optical digital
audio output from a DVD player, HDTV receiver, LD
player, satellite receiver, cable box, MiniDisc player or
recorder, or CD player to these jacks.The signal may
be either a Dolby Digital signal, a DTS signal or a
standard PCM digital source.
ª Coaxial Digital Inputs: Connect the coax digital
audio output from a DVD player, HDTV receiver, LD
player, satellite receiver, cable box,MiniDisc recorder or
CD player to these jacks.The signal may be either a
Dolby Digital signal, DTS signal or a standard PCM digital
source. Do not connect the RF digital output of an
LD player to these jacks.
NOTE: The default setting for the audio input associated
with DVD is the Coaxial Digital Input 1 ª. If you
connect the audio outputs of a DVD player to another
digital or analog audio jack, change the input setting
as shown on page 19.
‚ AC Power Cord: Connect the AC plug to an
unswitched AC wall outlet.
⁄ Switched AC Accessory Outlet: This outlet may
be used to power any device you wish to have turned
on or off at the same time as the AVR 130.Any device
connected to this outlet will be off when the AVR 130
is in the Standby mode, and power will be supplied to
the outlet when the AVR 130 is turned on.
¤ Unswitched AC Accessory Outlet: This outlet
may be used to power any AC device.The power will
remain on at this outlet regardless of whether the
AVR 130 is on or off.
IMPORTANT NOTE: The total power consumption of
all devices connected to the accessory outlets should
not exceed 100 watts. Do not connect power amplifiers
or other high-current-draw devices to these outlets.
‹ Optical Digital Output: Connect this jack to the
matching digital audio input connector on a digital
recorder such as a CD-R or MiniDisc recorder.
› Coaxial Digital Output: Connect this jack to the
matching digital audio input connector on a digital
recorder such as a CD-R or MiniDisc recorder.
fi S-Video Monitor Output: When your television
or other video display is equipped with an S-Video
input and you are using at least one video source
with S-Video capability, connect this jack to the S-
Video input on the video display.
fl DVD S-Video Input: If you are not making a
direct connection from the component video outputs
of your DVD player to a television or other video dis-
play, connect the S-Video output of the DVD player to
this jack and then make certain that the
S-Video
Monitor Output
fi is also connected as described
above.
‡ Video 1 S-Video Input: If the product connected
to the
Video 1 Audio Inputs d has S-Video capa-
bility, connect this jack to the PLAY/OUT S-Video jack
on that unit and then make cerain that the
S-Video
Monitor Output
fi is also connected as described
above.
° Video 1 S-Video Output: If the product
connected to the
Video 1 Audio Outputs e has
S-Video capability, connect this jack to the REC/IN
S-Video jack on that unit.
· Video 2 S-Video Input: If the product connected
to the
Video 2 Audio Inputs f has S-Video capa-
bility, connect this jack to the PLAY/OUT S-Video jack
on that unit and then make certain that the
S-Video
Monitor Output
fi is also connected as described
above.
a 6-Channel Direct Inputs: Connect the outputs of
a DVD Audio or SACD player,or another product with
built-in multichannel decoding, to these jacks.
These jacks have been color-coded as follows to
assist you in making correct channel connections:
Front Left White
Front Right Red
Center Green
Surround Left Blue
Surround Right Gray
Subwoofer Purple
b Video Monitor Output: Connect this jack to the
composite video input of a TV monitor or video
projector to view the output of any standard video
source selected by the receiver’s video switcher.
c DVD Audio/Video Inputs: Connect one of these
jacks to the composite video and L/R analog audio
output jacks on a DVD or other video source.
NOTE: The default setting for the audio input associated
with DVD is the Coaxial Digital Input 1 ª. If you
connect the audio outputs of a DVD player to another
digital or analog audio jack, change the input setting
as shown on page 19.
d Video 1 Audio/Video Inputs: Connect these
jacks to the
PLAY/OUT composite video jacks and
L/R audio jacks on a VCR or other video source.
e Video 1 Audio/Video Outputs: Connect these
jacks to the
RECORD/INPUT composite video and
L/R audio jacks on a VCR.
f Video 2 Audio/Video Inputs: Connect these
jacks to the
PLAY/OUT composite video and L/R
audio jacks on a TV, VCR or other video source.
g AM Antenna Terminals: Connect the AM loop
antenna supplied with the receiver to these terminals. If
an external AM antenna is used, make connections to
the
AM and GND terminals in accordance with the
instructions supplied with the antenna.
h FM Antenna Jack: Connect the supplied indoor or
an optional external FM antenna to this jack.
Note on Video Connections: When connecting a
source device such as a VCR, DVD Player, cable or
satellite set top box or video game to the AVR, use
either a composite or S-Video connection for each
input, but not both.
REAR-PANEL CONNECTIONS
