5 FRONT PANEL CONTROLS & INDICATORS
1 Power Switch: Press this switch to turn
the PA 2000 on for manual operation when the
Power Control Mode Switch £ for one or
both channel pairs is in the ON position, or to
place it in the Standby mode when the Power
Control Mode Switch £ for one or both
channel pairs is in either the Music Sense or
AC/DC Trigger position.
2 Power Indicators:These indicators will
light when either of the channel pairs is on.
3 Standby Indicators:These indicators will
light when AC mains power is applied to either
of the channel pairs, but when that channel
pair is not currently active. In this condition, the
channel pair associated with the indicator is
ready to turn on when a signal is applied to the
Trigger Jack § or when there is an audio
signal applied to the Input Jack ¡.
4 Protect Indicators:These indicators will
light when either of the channel pairs is in the
Protect mode.When one of these indicators
lights, turn the unit off immediately and check
for a problem, such as a short in the speaker
wiring.
Front Panel Controls and Indicators
1 Power Switch
2 Power Indicators
3 Standby Indicators
4 Protect Indicators
