Harman Kardon SUB-TS18 - Contents; Specifications

CONTENTS
BASIC SPECIFICATIONS . . . . . . . . . . . . ……………………………………. . . . 1
DETAILED SPECIFICATIONS. . . . . . . . . . . . . .. . . . . . . . . ………………….. …2
PACKAGING. . . . . . . . . . . . . .. . . . . . . ……………………… . . . . .. . .. .. .. . . . . 4
CONTROLS & CONNECTIONS . . . . . . . . . . . . . .. . . . . . . . . ………………….. 5
SPEAKER CONNECTIONS……………………….………..……. . . .. . .. . . . .. . .. 6
OPERATION……. . . . . .. . . . . . . . .. .. . . . .. .. . . . . ………………………………10
TEST PROCEDURE. . . . . . . . . . . ………………………………………………….11
UNIT EXPLODED VIEW. . . . …………… ……………. .. ………... . . .. .. ... . … . 12
AMPLIFIER EXPLODED VIEW. . . . ………………... . .. ………... . . .. . . .. . .… . 13
BLOCK DIAGRAM . . . . . . . . . . . . . .. . . . . . . ……………… . . . . .. . .. . .. . . . . 14
DETAILED TROUBLESHOOTING..…………………………………………………15
PCB DRAWINGS. .. . . . . . . . . . . . . . .. . . . . ……… . …………. . . . .. .. .. . .. . . . 16
ELECTRICAL PARTS LIST …………. .... . .. . . . …………………………... … . . 20
SEMICONDUCTOR PINOUTS . . . .. .. .. .. . . . .. . ……………..………..………. .24
SCHEMATIC DIAGRAMS . . . . . . . . .. .. .. .. . . . .. . ………………………..……. .25
SPECIFICATIONS
Amplifier Power (RMS) 200 Watts
Driver 10" (254mm) woofer, Bass Reflex Enclosure
Inputs Stereo Line Level, dedicated Subwoofer (LFE)
and Speaker Level with gold-plated binding posts
Outputs Speaker Level with gold-plated binding posts
Frequency Response 35Hz – 120Hz (Filter switch ON)
35Hz – 450Hz (Filter switch OFF)
External Trigger Input Voltage: 3-30 Volts AC/DC
Dimensions (H x W x D) 18-7/8" x 13-3/8" x 13-3/8" (479mm x 340mm x 340mm)
Weight 35.1 lb/15.8kg
Occasional refinements may be made to existing products without notice but will always meet or exceed original specifications
unless otherwise stated.
