Harman Kardon TC300 User Manual

Thank you for choosing a Harman Kardon
Tunnel Cooled amplifier. This is a superb
piece of high fidelity equipment that has
been meticulously designed to provide you
with many hours of enjoyment.
Harman Kardon's Tunnel Cooled amplifiers
are the result of an extensive engineering
project to create the finest automotive high-
fidelity amplifiers available. These amplifi-
ers provide superior performance, can
operate under extreme environmental
conditions, and are highly adaptable to
various system configurations.
This manual describes the features and
capabilities of your new amplifier. In
addition,
it describes the proper methods for
connecting your amplifier to your system.
Please read this owner's manual and care-
fully follow the instructions for connection.
Table of Contents
Harman Kardon design philosophy 2
4
........
TC600, TC300, and TC304 features ....... 3
............................................. introduction 5
Installation precautions ................... ..... 6
Charging system considerations ............. 7
................................... Mounting location 7
............................. System configurations 8
........ Connecting the TC-series amplifier
I I
General information ............................ I I
Power connections .............................. 13
Audio input connections
..................... 17
................. Speaker output connections 18
Controls and operation ............................ 19
Application drawings .............................. 22
Series-Parallel and minimum impedance
speaker connection
.............................. 29
Troubleshooting checklist ....................... 3 1
Fan reversal for multiple amplifier
......................................... installations 33
Specifications
.......................................... 34
