A . Design and Installation Considerations
1. Appliance Location
NOTICE: Checkbuildingcodespriortoinstallation.
 

       



    


 
 
          
         

         

Warning! Risk of Fire
Damaged parts could impair safe
operation.DoNOTinstalldamaged,incompleteorsubstitute
components.
CAUTION! If burning shelled eld corn, you must use
approvedventingspecicallydesignedforcorntoprevent
corrosion or degradation. Follow the instructions from the
ventingmanufacturer.
NOTICE: Locatingtheapplianceinalocationofconsiderable
airmovement can cause intermittent smoke spillagefrom
appliance.Donotlocateappliancenear:
• Frequentlyopendoors
• Centralheatoutletsorreturns
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 2.1
2
Getting Started


        

        


  

 
 
 
 
 
       

Suitable replaces for installation:
 
 
 
