SPECIFICATIONS
Electronic
Controls: Feedback, Momentary On/Off, Dry On/Off, Gain, Onset, Type, Effect On/
Off
Signal to Noise Ratio: > -106dB (A weighted); ref = max level, 22 kHz bandwidth
THD: 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
A/D/A Conversion: 24-bit
Input
Input Type: 1/4” Unbalanced TS (Tip-Sleeve)
Max Input Level: +5 dBu
Input Impedance: 1 MΩ (Effect enabled or effect bypassed w/ Momentary switch on)
True Bypass (Effect bypassed w/ Momentary switch off)
Output
Output Type: 1/4” Unbalanced TS (Tip-Sleeve)
Max Output Level: +10 dBu
Output Impedance: 1 kΩ (Effect enabled or effect bypassed w/ Momentary switch on)
True Bypass (Effect bypassed w/ Momentary switch off)
Physical
Dimensions: 4.75” (L) x 2.875” (W) x 1.75” (H)
Weight: 0.8 lbs. (0.363 kgs.)
Power
Power Consumption: 2.1 Watts (235 mA typical @ 9 VDC)
Power Requirements: 9 VDC External Adapter (sold separately)
Recommended Power Adapter (Not Included)
Power Adapter: PS0913DC-04 (US, JA, EU, AU, UK)
Power Adapter Polarity:
Power Adapter Output: 9 VDC 1.3 A
