v. ) BU-80/HTS-10 (re A,B ELECTRICAL PARTS LIST

Capacitors

C1, 2 30701 3300uF 50V ±20% Electrolytic Radial 2

SAFETY PART

C3 30504 100nF 50V  10% Mono-ceramic axial 1

C4, 5 30502 100nF 50V  20% Mono-cer rad 2

0.2"/ax 0.3"

C6 30705 10uF 50V  20% Electrolytic Radial NP 1

SAFETY PART

See page 15 (ServiceBulletinINF2000-01 )

C7 30503 2.2nF 50V  10% Mono-ceramic axial 1

C8, 10 30504 100nF 50V  10 Mono-ceramic axial 2

C9 30502 100nF 50V  20% Mono-ceramic axial 1

C11 30702 100uF 35V  20% Electrolytic Radial 1

C12 30703 4.7uF 35V  20% Electrolytic Radial 1

C13 30506 1nF 50V  10% Mono-ceramic axial 1

C14 30504 100nF 50V  10% Mono-ceramic axial 1

C15, 16 30704 220uF 50V  20% Electrolytic Radial Bipolar 2

C17 30502 100nF 50V  20% Mono-ceramic axial 1

C18, 19, 20 30504 100nF 50V  10% Mono-ceramic axial 3

C21 30508 10nF 50V  10% Mono-ceramic axial 1

C24 30502 100nF 50V  20% Mono-ceramic axial 1

C25 30503 2.2nF 50V  10% Mono-ceramic axial 1

C28 30507 10nF 50V  20% Mono-ceramic axial 1

C7A, 7B 30505 100nF 100V  20% Metal Polyester Rad 2

Resistors

R1 40403 2200k 1/4W  5% carbon film 1

R2 40447 4.32k 1/4W  1% metal film 1

R3 40412 33.2k 1/4W  1% metal film 1

R5, 6 40420 1k 1/4W  5% carbon film 2

R7 40409 10k 1/4W  5% carbon film 1

R8 40406 100k 1/4W  5% carbon film 1

R9 40421 3.9k 5W  5%, 3W can be used 1

R10 40404 1k 2W  5% carbon film 1

R11, 12 40107 150 1/2W  5% carbon film 2

R13 40404 1k 2W  5% carbon film 1

R14 40405 4.7k 1/4W  5% carbon film 1

R15 40406 100k 1/4W  5% carbon film 1

R16, 17 40101 820 2W  5% carbon film 2

R18 40423 270k 1/4W  5% carbon film 1

R19 40422 1k 1/2W  5% carbon film 1

R20 40405 4.7k 1/4W  5% carbon film 1

R21 40409 10k 1/4W  5% carbon film 1

R22 40449 3.3k 1/2W  5% carbon film 1

R26 40701 1000k 1/4W  5% carbon film 1

R27 40411 24.9k 1/4W  1% metal film 1

R28 40409 10k 1/4W  5% carbon film 1

R29 40103 470 1/4W  1% METAL SAFETY PART 1

R30 40413 274k 1/4W  1% metal film 1

R31 40414 49.9k 1/4W  1% metal film 1

R32 40415 470k 1/4W  5% carbon film 1

R35 40416 221k 1/4W  1% metal film 1

R36 40406 100k 1/4W  5% carbon film 1

R37 40417 47k 1/4W  5% carbon film 1

R38 40406 100k 1/4W  5% carbon film 1

R39 40448 28k 1/4W  5% carbon film 1

R40 40431 68k 1/4W  5% carbon film 1

R42, 43 40406 100k 1/4W  5% carbon film 2

R44, 45 40409 10k 1/4W  5% carbon film 2

R46 40104 4.7 1/4W  5% carbon film 1

R48 40428 8.2k 1/4W  1% metal film 1

R49 40431 68k 1/4W  5% carbon film 1

R4A, 4B 40105 0.1 1/2W  5% 2pcs. 2

R53, 54, 55, 56 40106 100 2W  5% carbon film 4

R57 40406 100k 1/4W  5% carbon film 1

FRQ pot 40401 100k 1/4W  10% Single Log Pot 1

VOL Level pot 40402 5k 1/4W  10% Single Linear Pot 1

Diodes

D1 50101 ZENER 1N5256B 30V 5% 0.5W 1

D3 50102 ZENER 1N4749A 24V 5% 1W 1

D6 50103 ZENER 1N5234B 6.2V 5% 0.5W 1

D7, 8 50104 1N4148 100V  5% 0.1A 2

D9, 10 50105 ZENER 1N4744A 15V  5% 1W 1

DBR 50100 Bridge Rect 200V 4A SAFETY PART 1

LED 1 or 2 50106 Dual Cir LED (2 legged) 2

IntegratedCircuit

U1 60100 LM324 Quad OpAmp +/-15% 1

S53AMI 60301 Power Amp module SAFETY PART 1

Transistors

Q1 60151 MPS A13 30V NPN(Darl) Transistor 1

Q2 60152 2N3906 40V PNP Transistor 1

Q3 60153 2N3904 40V NPN Transistor 1

Q4, 5 60154 MPS A56 80V PNP Transistor 2

Miscellaneous

CMC1 80100 mc4438 Neosid 28-523C36 2X 2.2mH

#23 awg @ 2X 24 SAFETY PART

L1 80101 mc4436 Neosid 32-192-44 200uH

#18SNSR @ 3 6 SAFETY PART

L2 80102 BL02RN2-R62

Amplifier/Subwoofer BU-80/HTS-10

REF# PART# DESCRIPTION QTY REF# PART# DESCRIPTION QTY
