Amplifier/Subwoofer BU-80/HTS-10
Min50
Max150
Volume
Crossover
Frequency
TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT
EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
120VAC
60Hz
100W
R
R
L
L
Power
SPKR
IN
SPKR
OUT
Low-Level In
BU-80 HTS-10“or”
Digital
Technology
123 5
4
CONTROLS AND THEIR FUNCTION
1. High-Level input and Output terminals
2. Low-Level Input Jacks: connect to preamplifier outputs
3. Crossover Frequency: controls upper-corner roll-off points.
4. Power-On indicator
5. Volume Control: controls volume of subwoofer.
To Next Page
