Harman Infinity REFERENCE 4555A - Mechanical Exploded View; Product Assembly Diagram

noitpircseDN/PmetI
1 MK0101100772 LOGO PC 351.6*138.9*5.0MM REF-4555a
2 MK0101100771 LOGO BRACKET PC 49*136.3*3.0MM REF-4555a
10 SG0101100064 3P AC SOCKET REF-4555a
15 MK0101700706 FUSE COVER
16 SG0101100063 2P SPEAKER JACK BRACKET REF-4555a
17 SG0101100065 4P SPEAKER JACK BRACKET REF-4555a
22 88FA03200419 PRE AMP PCBA 4505, 4555a
27 MK0101100764 6P RCA COVER REF-4555a
38 88MA03200798 MAIN PCBA 4505, 4555a
REF-4555A MECHANICAL EXPLODED VIEW
