INFINITY REFERENCE 4555A SPARE PARTS LIST
Pos. No. P/N Description
1 MK0101100772 LOGO PC 351.6*138.9*5.0MM REF-4555a
2 MK0101100771 LOGO BRACKET PC 49*136.3*3.0MM REF-4555a
10 SG0101100064 3P AC SOCKET REF-4555a
15 MK0101700706 FUSE COVER
16 SG0101100063 2P SPEAKER JACK BRACKET REF-4555a
17 SG0101100065 4P SPEAKER JACK BRACKET REF-4555a
22 88FA03200419 PRE AMP PCBA 4505, 4555a
27 MK0101100764 6P RCA COVER REF-4555a
38 88MA03200798 MAIN PCBA 4505, 4555a
FUSE1 140203000050 FUSE 30A 32V 4505, 4555a
JK1 120303000031 HEADPHONE JACK 4505, 4555a
Q6,Q7,Q8,Q10,Q11
,Q12
050403000085 IRF3205 TO-263 4505, 4555a
Q69A,Q69B,Q69C,
Q69D
050103000139 Transistor DIP D718 TO-3PNP 6A 60W 4505, 4555a
Q70A,Q70B,Q70C,
Q70D
050103000138 Transistor DIP B688F TO-3PNP 6A 60W
Q9E,Q10E,Q11E,Q
12E
050403000005 DIP IRFB 38N20D TO-220 4505, 4555a
RCA1 120203000085 RCA CONNECTOR AV6-8.4-13A 4505, 4555a
RJ1 121103000003 NETWORK SOCKET RJ45-10P8C 8PIN 4505, 4555a
SW1 110103000061 SLIDE SWITCH 8P3T 4505, 4555a
SW2,SW3 110103000062 BAND SWITCH 14*6.5*8.5H 2P3T 4505, 4555a
SW4 110203000016 ROTARY SWITCH RS9A10-148-SB6.4F1.0-00 4505, 4555a
SW5,SW6 110103000017 BAND SWITCH SHC-22P-09 2P2T 4505, 4555a
T1 110603000027 TEMP. SWITCH 80Ԩ 4505, 4555a
T2 110603000021 TEMP. SWITCH JUC-31F 95Ԩ土3Ԩ 4505, 4555a
T3 200403000217 TRANSFORMER Ф47 DC24V/400W DC62V/500W 4505, 4555a
U1P 060103000383 IC. TL494C SO-16 4505, 4555a
U2E 060103000026 IRS2092 SOIC16N 4505, 4555a
VR1,VR2,VR5,VR6,
VR7
010703000363 POTENTIOMETER B20K ±10% 4505, 4555a
VR3,VR4 010703000359 POTENTIOMETER C100K ±10% 4505, 4555a
CH0102000639 BEAUTY BOX REF-4555a
LS0201000323 HEXAGON SCREW 55.8*4MM
