12
IRX108BT SPECIFICATIONS
Bottom View Front View Left View Rear View
486
313
258
618
400
299
IRX108BT
IRX112BT
TECHNICAL SPECIFICATIONS
SYSTEM TYPE: Powered 8” two-way
CABINET: Polypropylene with full grille
SENSITIVITY (SPL): 124 dB peak
FREQUENCY RESPONSE (±3 dB): 54 Hz – 20 kHz
POWER RATING: 1300 watts peak
INPUT IMPEDANCE: 10k ohm balanced
COVERAGE PATTERN: 90º (horizontal) x 60º (vertical) nominal
BLUETOOTH: Audio streaming, Bluetooth version 5.0
DSP: 4 presets, feedback suppression, ducking
I/O: 2 XLR/TRS combo mic/line inputs, 1 XLR pass-thru output 35
mm pole socket
MOUNTING: 17.4 lb (7.9 kg)
NET WEIGHT: 10.15 x 12.32 x 19.15 in
DIMENSIONS (D x W x H): (258 x 313 x 486 mm)
ORDER SPECIFICATIONS
SHIPPING CARTON (L x W x H): 10.87 x 13.35 x 20.35 in
(276 x 339 x 517 mm)
SHIPPING WEIGHT: 20.5 lb (9.3 kg)
UPC COD 691991033506
