Harman JBL QUANTUM TWS - Controls on Charging Case; Controls on 2.4 Ghz USB Wireless Dongle

- 4 -
Controls on charging case
05
04
03
01
02
01 Earbud holder
02 Dongle holder
03 LED indicator
04 Charging pin
05 Charging port
Controls on 2.4GH z USB wireless dongle
02
01
01 Pairing button
• Hold for more than 5 seconds to enter 2.4GHz wireless pairing mode.
02 LED indicator
• Indicates the status of 2.4GHz wireless connection.
