003 OVERVIEW
04
06
10
11
01 Game audio-chat balance dial
02 Volume Control
03 Microphone Mute / unMute
04 CHARGING LED
05 USB-C port
06 2.5mm jack for boom microphone
07 Flat-fold ear cup
08 POWER / 2.4GHz / Bluetooth LED
09 Power on / off and Bluetooth
pairing slider
10 2.4GHz LED
11 2.4GHz PAIRING BUTTON
05
03
02
08
09
07
01
