Stage 2 Architectural Loudspeakers Installation Guide | ©2022 Harman International Pg 3
Safety Warnings
IMPORTANT!
HARMAN International assumes no
responsibility for improper installation of hardware or for
any personal injuries or product damages resulting from
improper installation or a fallen loudspeaker.
Read through this document in its entirety and heed all
warning before proceeding with the installation of these
product(s).
IMPORTANT! Installation Precautions
Due to the nature of this product, there are several
precautions to follow before installation can begin.
1. Allowsufcientclearancebetweenthespeakerandany
insulation that may be in the wall cavity to avoid ignition
should overheating occur.
1" (26mm) for Non-Flammable Materials
3" (78mm) for Flammable Materials
2. Ensure that all wire run inside of walls and ceiling meets
orexceedslocalrecodesforhiddenwiring.
3. Determine wire lengths and select the proper gauge
speaker wire to use based on the table under Wire Gauge
by Distance.
4. Do
NOT
overtighten the dog legs when securing the
speaker to surfaces as this may cause the speaker to
come loose. If using a power screwdriver set it to the
lowest settings.
5. Do
NOT
connectthespeakerstoanamplierrated
abovetherecommendedamplierpower.Overdrivingthe
speaker can cause an overheating condition increasing
the risk of injury.
6. Do
NOT
connecttheamplierendofthewireuntilall
speakers are wired and installed.
7. Determine and purchase any accessories such as pre-
construction brackets before beginning the installation
process. Refer to Associated Accessories for a list of
available brackets.
8. Ensure that wall and ceiling board material is between ½"
(13mm) and 2" (51mm) thick and capable of supporting
the weight of the speaker.
To Next Page
