Harman JBL Stage A6002 Service Manual

Spare Parts List v1.0
Pos. No. Product Name P/N Description Usage
10 Stage-A6002 Primus-6002a 06-020548-2100-0-N MAIN BOARD A6002/6002A 1
11 Stage A6002, Primus 6002a 9006095002006 INSULATION TAPE W/O GLUE A6002/6002A 1
12 Stage A6002, Primus 6002a 20M0070000002 DEPRESSION BAR 38MM A6002/6002A 1
13 Stage A6002, Primus 6002a 20M0070000001 DEPRESSION BAR 28MM A6002/6002A 1
15 Stage A6002, Primus 6002a 20M0070000003 DEPRESSION BAR 21MM A6002/6002A 1
17 Stage A6002, Primus 6002a 9006095002004 INSULATION TAPE W/GLUE A6002/6002A 1
C1 C2 Stage A6002, Primus 6002a 10C5332740001 CAP. 3300U/25V 土20% 105Ԩ A6002/6002A 2
C17 C18 Stage A6002, Primus 6002a 10C6222750001 CAP. 2200UF/35V ±20% A6002/6002A/A9004/9004A 2
CON2 Stage A6002, Primus 6002a 10J500004P001 CONNECTOR 4P JSZ4-03 A6002/6002A 1
CON3 Stage A6002, Primus 6002a 10J500003P001 CONNECTOR 3P JSZ3-03 A6002/6002A/A9004/9004A 1
D16 Stage A6002, Primus 6002a 10D71620CT001
HALF
-
BRIDGE
MUR1620CTR
A6002/6002AA9004/9004A
1
D17 Stage A6002, Primus 6002a 10D71620CT002 HALF-BRIDGE MUR1620CT A6002/6002AA9004/9004A 1
J1 Stage A6002, Primus 6002a 10J528413A001 CONNECTOR RCA A6002/6002A 1
L7 Stage A6002, Primus 6002a 10L0270000001 TRANSFORMER D27*12-16 A6002/6002A 1
LED1 Stage A6002, Primus 6002a 10D4260030001 LED D3 RED/BLU 3P A6002/6002A/A9004/9004A 1
Q11 Q12 Stage A6002, Primus 6002a 10T0RF3205001 MOS TUBE IRF3205 A6002/6002A/A9004/9004A 2
SW1 Stage A6002, Primus 6002a 10K0010000002 SWITCH 2P3T L8MM A6002/6002A/A9004/9004A 1
TR1 Stage A6002, Primus 6002a 10R4501000002 NTC THERMISTOR 10K A6002/6002A/A9004/9004A 1
U1 Stage A6002, Primus 6002a 10I0DA8920001 IC TDA8920CTH AMP A6002/6002A 1
U2 Stage A6002, Primus 6002a 10I0078L05001 REGULATOR 78L05 A6002/6002A/A9004/9004A 1
U3 Stage A6002, Primus 6002a 10I0J78L12001 IC CJ78L12 A6002/6002A/A9004/9004A 1
U4 Stage A6002, Primus 6002a 10I0J79L12001 IC CJ79L12 A6002/6002A/A9004/9004A 1
U5 Stage A6002, Primus 6002a 10I00TL494001 IC TL494CD A6002/6002A/A9004/9004A 1
U6 U7 U9 Stage A6002, Primus 6002a 10I0L084CN001 IC TL084CN A6002/6002A/A9004/9004A 3
U8 Stage A6002, Primus 6002a 10I0L082CN001 IC TL082CN A6002/6002A/A9004/9004A 1
VR1 Stage A6002, Primus 6002a 10R6200000001 POTENTIOMETER B20K A6002/6002A/A9004/9004A 1
VR3 VR2 Stage A6002, Primus 6002a 10R6100000001 POTENTIOMETER C100K A6002/6002A/A9004/9004A 2
VR4 Stage A6002, Primus 6002a 10R6500000001 POTENTIOMETER B500K A6002/6002A/A9004/9004A 1
Stage A6002, Primus 6002a 10F2200000001 FUSE 20A A9004/9004A/A6002/6002A 1
Stage A6002 50B30A6002001 GIFT BOX A6002 1
Primus 6002a 50B306002a001 GIFT BOX 6002A 1
Stage-A6002 Primus-6002a 40S8000300009 5P HIGH INPUT CABLE A6002/6002A 1
Stage 20M0070157001 JBL LOGO STAGE AMP 1
Primus 20M0070158002 INFINITY LOGO PRIMUS AMP 1

Harman JBL Stage A6002 Specifications

General

Channels	2
Frequency Response	20 Hz - 20 kHz
Input Sensitivity	200 mV - 4 V
THD @ Rated Power	< 1%
Signal-to-Noise Ratio	> 80 dB
Crossover Frequency	50 Hz - 200 Hz
Dimensions (H x W x L)	2.1" x 9.8" x 13.4"
