Harman JBL Stage A6002 User Manual

HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
©2018 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of HARMAN International
Industries, Incorporated, registered in the United States and/or other countries. Features, specifications and appearance
are subject to change without notice.
There’s Nothing Better Than Riding With JBL
Stage Amplifiers
What’s in the Box
Amplifier
Spare Fuse (x2 for 1-channel and 4-channel model)
Quick start guide
High-level input cable (x2 for 4-channel model)
2x two-color JBL Brand Stickers
Mounting hardware
Mounting screws
Technical Specifications:
Stage A6002
Operating voltage 9 – 16V
RMS power @ 4 ohms 60W
RMS power @ 2 ohms 70W
RMS bridged power @ 4 ohms 140W
Total peak power 280W
Frequency response 20Hz – 20kHz @ -1dB
THD + N at rated power
(20Hz – 20kHz) <1%
Line-in signal-to-noise ratio
(reference to 1 watt) >75dB
Maximum high input signal level 12V
High input maximum sensitivity 0.5V
Maximum line input signal level 5V
Line input maximum sensitivity 0.2V
Quiescent current draw <1.0A
Fuse size 20A
Dimensions (H x W x L) 50 x 145 x 156.6mm
Weight 1.16kg
Stage A6004
Operating voltage 9 – 16V
RMS power @ 4 ohms 60W
RMS power @ 2 ohms 70W
RMS bridged power @ 4 ohms 140W
Total peak power 560W
Frequency response 20Hz – 20kHz @ -1dB
THD + N at rated power
(20Hz – 20kHz) <1%
Line-in signal-to-noise ratio
(reference to 1 watt) >75dB
Maximum high input signal level 12V
High input maximum sensitivity 0.5V
Maximum line input signal level 5V
Line input maximum sensitivity 0.2V
Quiescent current draw <1.2A
Fuse size 2 x 15A
Dimensions (H x W x L) 50 x 145 x 193.6mm
Weight 1.381kg
Stage A9004
Operating voltage 9 – 16V
RMS power @ 4 ohms 90W
RMS power @ 2 ohms 110W
RMS bridged power @ 4 ohms 220W
Total peak power 880W
Frequency response 20Hz – 20kHz @ -1dB
THD + N at rated power
(20Hz – 20kHz) <1%
Line-in signal-to-noise ratio
(reference to 1 watt) >75dB
Maximum high input signal level 12V
High input maximum sensitivity 0.5V
Maximum line input signal level 5V
Line input maximum sensitivity 0.2V
Quiescent current draw <1.5A
Fuse size 2 x 20A
Dimensions (H x W x L) 50 x 145 x 268.6mm
Weight 1.806kg
Stage A3001
Operating voltage 9 – 16V
RMS power @ 4 ohms N/A
RMS power @ 2 ohms 300W
RMS bridged power @ 4 ohms N/A
Total peak power 600W
Frequency response 10Hz – 320kHz @ -3dB
THD + N at rated power
(20Hz – 20kHz) <1%
Line-in signal-to-noise ratio
(reference to 1 watt) >75dB
Maximum high input signal level 12V
High input maximum sensitivity 0.5V
Maximum line input signal level 5V
Line input maximum sensitivity 0.2V
Quiescent current draw <1.5A
Fuse size 2 x 15A
Dimensions (H x W x L) 50 x 145 x 241.6mm
Weight 1.609kg
