Page #11 background imageLoading...
Page #11 background image
11
www.jbl.com
SPECIFICATI ONS
STUDIO 698
Dual 8", 6" mid, 3-way compression driver floor standing loudspeaker
6" (152mm) PolyPlas Mid-range Transducer
Dual 8” (203mm) PolyPlas cone Low-Frequency Transducer
High Definition Imaging (HDI) Waveguide with 1” (25mm) High Frequency Compression Driver
Recommended Amplifier Power: Max 250W
Frequency Response: 36 Hz - 40 kHz
Sensitivity: 90 dB, 1M, @ 2.83V
Nominal Impedance: 6 Ohms
Crossover Frequencies: 320 Hz, 1.8 kHz
Enclosure Type: Bass-Reflex via Rear-Firing Tuned Port
Dimensions (W x D x H): 300 x 400 x 1058 mm
35.84 kg
Weight:
STUDIO 690
Dual 8", 2.5-way compression driver floor standing loudspeaker
Dual 8" (203mm) PolyPlas Low-Frequency Woofer
High Definition Imaging (HDI) Waveguide with 1” (25mm) High Frequency Compression Driver
Recommended Amplifier Power: Max 250W
Frequency Response: 36 Hz - 40 kHz
Sensitivity: 90 dB, 1M, @2.83V
Nominal Impedance: 6 Ohms
Crossover Frequencies: 600 Hz, 1.7 kHz
Enclosure Type: Bass-Reflex via Rear-Firing Tuned Port
Dimensions (W x D x H): 300 x 350 x1058 mm
Weight: 29.38 kg
English
