Harman JBL SUB 550P User Manual

190-16L431CLP1-E IC TL431CLP (RoHS) 1 D115,
190-16LM324N-E I.C. LM324N (RoHS) 1 U107,
192-027C1815GR-E Transistor 2SC1815GR TOSHIBA(RoHS) 4 Q110,Q112,Q114,Q117,
192-028A1015GR-E Transistor 2SA1015GR TOSHIBA(RoHS) 3 Q111,Q113,Q115,
192-1572N5551-E *Transistor FSC 2N5551 TAP (RoHS) 1 Q109,
192-1582N5401-E Transistor FSC 2N5401 AI-PNP 350V500mA TO-92
(
RoHS
)
1 Q108,
192-991SD669AL-E TransistorUTC 2SD669AL 180V 1.5ATO-126C RoHS 1 Q116,
192-992SB649AL-E TransistorUTC 2SB649AL-180V-1.5ATO-126C RoHS 1 Q118,
197-00KBU1003-E Rectifier10A 200V KBU1003(RoHS) 1 D123,
197-60DB103G-E Rectifier1A 200V DI102 DB103GRoHS 1
197-631N4002-E Diode 1N4002 100V 1.0A (RoHS) 1 D114,
197-631N4148-E Diode 500mW 75V 1N4148 PanjitTAP (RoHS) 7 D117,D118,D119,D120,D
121
,
D125
,
D126
,
199-65000563G-E Diode GDZJ5.6B 500mW 5.6V26mm TAP 2%
(
RoHS
)
1 D116,
199-65001503G-E Diode GDZJ15C500mW 15V 2%ROHM 52mm TAP
1N245B
(
RoHS
)
1 D122,
199-65002003G-E Diode GDZJ20D 500mW 20V26mm TAP 2%
(
RoHS
)
1 D129,
362-FE-00041-0LAE PCB Stand 11.75*8.5*12.5H(RoHS) 1
052-A05288B-E AI PCB ASS'Y OF 230V EUPPOWER RoHS 1
118-08051002J-E SMD Resistor 0805 1/10W 10KΩ ±5%LF 3 R10,R14,R05,
118-08051003J-E SMD Resistor 0805 1/10W 100KΩ ±5%LF 1 R16,
118-08051104J-E SMD Resistor 1.1Mohm 5% 0805(RoHS) 2 R03,R04,
118-08052001J-E SMD Resistor 0805 1/10W 2K ±5% LF 2 R06,R17,
118-08052202J-E SMD Resistor 0805 1/10W 22KΩ ±5%LF 1 R15,
118-08053832F-E SMD Resistor 0805 1/10W 38.3KΩ 1%(RoHS) 1 R08,
118-12060000J-E SMD Resistor 1206 1/4W 0 ±5%LF/RoHS 3 R19,R20,R21,
118-12062R00J-E SMD Resistor 1206 2Ω 5% (RoHS) 2 R11,R12,
118-12063003J-E SMD Resistor 1206 1/4W 300K ±5%(RoHS) 2 R01,R02,
120-14330J3-E Inductor 33uH ±5% TAP(RoHS) 2 L1,
135-3337M10-E Capacitor 330U 10V ±20% TAP(RoHS) 4 C09,C10,C12,C14,
135-3476M35-E Capacitor 47uF 35V ±20% TAP(RoHS) 1 C18,
141-B0681J50-E SMD Capacitor0805 680pF NPO50V 5%(RoHS) 1 C20,
141-B5104M50-E SMD Capacitor0805 Y5V 0.1uF50V ±20% (RoHS) 6 C04,C08,C13,C16,C17,C2
141-B7223K50-E Capacitor0.022 50V 10%X7R 0805 (RoHS) 1 C22,
190-16L431CLP1-E IC TL431CLP (RoHS) 1 U1,
192-9918050DS-E audion 8050D sot-23 (RoHS) 1 Q01,
192-992S8550S-E SMD Transistor S8550 (RoHS) 1 Q04,
197-03RLS4148S-E *SMD Diode RLS4148-TE11 ROHM1206 RoHS 1 D10,
197-631N4007-E Diode PANJIT 1N4007 TAP(RoHS) 2 D03,D07,
051-A05293B-E OCB ASS'Y OF 230V EUPPOWER RoHS 1
109-1CK2R55A0-E Resistor SCK-2R55A(RoHS)SCK102R55AMSY 1 RT1,
109-3TVR10471KS0-E
Resistor TVR10471KS 42Y 長腳(RoHS)
1 RV1,
122-14103M4201-E
Inductor RT251510-103NBS 10mH 立式(RoHS)
1 L2,
130-2B102ME03-E Capacitor 1000PF 500V ±20% TAP(RoHS) 1 C02,
SUB 550P / 230
15

Harman JBL SUB 550P Specifications

General

Brand	Harman
Model	JBL SUB 550P
Category	Amplifier
Language	English
