Harman JBL SUB 550P - Page 16

130-2B471KJ03-E Capacitor 470P 1000V ±10% TAPY5P (RoHS) 1 C07,
130-2F331MD00-E Capacitor 330pF 250V ±20% LS= 10mm (RoHS) 1 C03,
132-103KB74-E Capacitor 0.01UF 10% 275V (RoHS) 1 C15,
132-224KB70-E Capacitor 0.22uF 275V ±10% (RoHS) 1 C19,
132-224KB74-E Capacitor CBB-0.22uFK 5% 275VACX2 (RoHS) 1 C06,
135-B156MD0-E
Capacitor 15uF 400V 105℃ ±20%TAP (RoHS)
1 C01,
150-SEE01902-E Transformer
(
EE19
)
(
RoHS
)
1 TR1,
154-V02507T1-E Fuse ICP 0.25A 250V 10mm VDE RoHS 1 FUSE,
156-H010010-E Heat shrink tube 1ψ*10mm (RoHS) 2 FOR,D08,
161-506520-E JUMPER WIRE 26mm TAP
(
RoHS
)
1 R18,
162-5020D014-E Wire UL1007 UL1007 22AWG4PIN HOUSING(RoHS) 1 CON2,
171-CS112LMR-E Relay SDT-S-112LMR (RoHS) 1 K1,
175-1D03V04-E Connector 3PIN PITCH=3.9mm IST (RoHS) 2 CN01,CN03,
190-99PC817C-E IC PC817C(COSMO) (RoHS) 1 OP1,
190-99THX203H-E I.C (RoHS) 1 IC1,
197-30SF16-E Rectifier SF16 (RoHS) 1 D08,
197-631N4007-E Diode PANJIT 1N4007 TAP(RoHS) 2 D01,D05,
197-63PS204R-E Diode PS204R (DO-15) (RoHS) 2 D02,D09,
197-63UF1010-E Diode UF1010 (DO-41) (RoHS) 1 D06,
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 1
051-A05380B-E PCB ASS'Y CLASS D 300W OFSUB550P RoHS 1
112-10180J00-E Resistor FMF 1W 18Ω 5%(RoHS) 1
118-12061001F-E SMD Resistor 1K 1206 1% (RoHS) 2 R2,R11,
118-12061002F-E SMD Resistor 10K 1206 1% (RoHS) 1 R25,
118-12061002J-E SMD Resistor 10.0K 1206 5% (RoHS) 5 R29,R30,R30B,R7,R9,
118-120610R0J-E SMD Resistor 10.0Ω 1206 5% (RoHS) 4 R20,R20B,R22,R23,
118-12062002F-E SMD Resistor 20K 1206 1% (RoHS) 1 R26,
118-12062201J-E SMD Resistor 2.20K 1206 5% (RoHS) 18 R13,R16,R31,R33,R34,R3
5,R36,R37,R38,R39,R40,
R41,R42,R43,R44,R45,R4
118-12062204J-E SMD Resistor 2.20M 1206 5% (RoHS) 1 R4,
118-12062211F-E SMD Resistor 2.21K 1206 1% (RoHS) 1 R6,
118-12062550F-E SMD Resistor 1206 255Ω 1% (RoHS) 1 R24,
118-12062701J-E SMD Resistor 2.70K 1206 5% (RoHS) 1 R10,
118-12063300J-E SMD Resistor 330Ω 1206 5% (RoHS) 1 R21,
118-12063301J-E SMD Resistor 3.30K 1206 5% (RoHS) 4 R14,R15,R27,R28,
118-12063321F-E SMD Resistor 3.32K 1206 1% (RoHS) 1 R1,
118-12063922F-E SMD Resistor 1206 39.2K±1% (RoHS) 1 R3,
118-12064700J-E SMD Resistor 470Ω 1206 5% (RoHS) 1 R8,
118-12064701J-E SMD Resistor 4.7K 5% 1206(RoHS) 1 R12,
118-12064751F-E SMD Resistor 4.75K 1206 1% (RoHS) 1 R5,
122-13151K0190-E CHOKE SA-500-280(PT1601B*151MAA) (RoHS) 1 L1,
122-14300K4-E Ferrite core LD1215*300KU±10% RoHS 1 L2,
128-E106MA01-SE Capacitor10uF 100V 20% (RoHS) 2 C16,C17,
