129-A104JA03-E Capacitor 0.1U 100V ±5% MSCTAP (RoHS) 2 C12B,C14,
130-SL681KB03-E CapacitorSL 680PF 200V (RoHS) 1
132-104KB50-E Capacitor0.1U ±10% 250V (RoHS) 1 C20,
132-105KB50-E Capacitor1uF 250V ±10% (RoHS) 1 C40,
141-C0101K50-E SMD Capacitor100pF 50V 10%1206 NP0 (RoHS) 1 C4,
141-C0220K50-E SMD Capacitor22pF 50V 10% 1206SMT NPO (RoHS) 1 C5,
141-C0561K50-E SMD Capacitor560pF 50V 10%1206 NPO (RoHS) 1 C6,
141-C5104M50-E SMD Capacitor1206 Y5V 0.1uF50V ±20% (RoHS) 8 C2,C3,C7,C8,C9,C10,C11
,C15,
141-C7223K50-E SMD Capacitor0.022uF 50V 10%1206 X7R (RoHS) 1 C13,
141-D7104KB5-E SMD Capacitor0.1uF 250V 10%1210 X7R (RoHS) 2 C18,C19,
156-H010005-E Tube 5mm ψ1 (RoHS) 1 C40,
156-H010020-E
Heat shrink tube 1￠*20mm (RoHS)
1 C40,
163-11209-E Cabel tie 120mm (RoHS) 2
175-9F02H02-E Connector 2PIN PITCH=2.54mm(RoHS) 1 HDR3,
175-9F03H020-E Connector 3PIN PITCH=2.54mm(RoHS) 2 HDR1,HDR2,
190-16TL072DTS-E SMD I.C. TL072CDT SGS THOMSON(RoHS) 1 IC1,
192-09124126QS-E SMD Transistor 2SC2412K-T146Q/RROHM (RoHS) 2 Q1,Q4,
192-09139066RS-E SMD Transistor 2SC3906K-T146R ROHM(RoHS) 2 Q2,Q8,
192-091SC4672-E Transistor 2SC4672(MPT3) ROHM(RoHS) 1 Q5B,
192-09210376QS-E SMD Transistor 2SA1037K-T146Q/RROHM (RoHS) 2 Q7,Q9,
192-09215146RS-E SMD Transistor 2SA1514K-T146R ROHM(RoHS) 1 Q3,
192-1582N5401-E Transistor FSC 2N5401 AI-PNP 350V500mA TO-92
(R HS)
1 Q6B,
192-232IRF9640-E FET IRF9640 IR P-CH TO220(RoHS) 2 Q10,Q10B,
192-233F640N-E Transistor IRF640N INTERNATIONAL(RoHS) 1 Q11,
197-03RLS4148S-E *SMD Diode RLS4148-TE11 ROHM1206 RoHS 8 D1,D2,D3,D4,D5,D5B,D6,
D20,
199-15000563S-E SMD ZENER 5.6V 5% PHILIPSBZX84-C5V6(RoHS) 2 Z1,Z2,
199-1500120S-E SMD ZENER 12V 5% PHILIPSBZX84-C12 RoHS 4 Z3,Z4,Z5,Z6,
359-FIB-00125-E Gasket 10*5*0.5T (RoHS) 2
051-A05381A-E PCB ASS'Y OF SUB550/230 PREAMP EUP RoHS 1
110-14152J26-E Resistor 1.5K 1/4W ±5% CF 26mmTAP(RoHS) 1 R150,
110-16000J26-E Resistor 0Ω 1/6W ±5% CF 26mm TAP(RoHS) 2 R190,R191,
110-16101J26-E Resistor 100Ω 1/6W ±5% CF 26mmTAP (RoHS) 2 R112,R113,
110-16103J26-E Resistor 10K 1/6W ±5% CF 26mm TAP(RoHS) 7 R263,R118,R133,R136,R
146,R149,R199,
110-16105J26-E Resistor 1M 1/6W ±5% CF 26mm TAP(RoHS) 1 R145,
110-16151J26-E Resistor 150Ω 1/6W ±5% CF 26mmTAP (RoHS) 1 R139,
110-16183J26-E Resistor 18K 1/6W ±5% CF 26mm TAP(RoHS) 1 R147,
110-16203J26-E Resistor 20K 1/6W ±5% CF 26mm TAP(RoHS) 1 R200,
110-16221J26-E Resistor 220Ω 1/6W ±5% CF 26mmTAP (RoHS) 2 D101,D102,
110-16223J26-E Resistor 22K 1/6W ±5% CF 26mmTAP (RoHS) 2 R141,R148,
110-16333J26-E Resistor 33K 1/6W ±5% CF 26mmTAP(RoHS) 1 R140,
110-16432J26-E Resistor 4.3K 1/6W ±5% CF 26mmTAP (RoHS) 1 R254,
