Installing the P42i Pellet Insert into an existing
factory built wood burning replace
When installing the P42i-TC Pellet Insert into a factory
built wood burning replace, the Manufactured Fireplace
Installation Kit #1-00-574205 must be used. In addition,
several things need to be taken into consideration.
The size of thereplace opening. Willtheunit t intothe
opening? Many of these units have metal smoke shields
insidethetopthatcanberemovedtogainheight.Oftenthe
side and rear refractory can be removed to gain depth and
width.Insomecircumstances,thefrontlowerliporgrillwork
may also be removed. Be sure and follow the guidelines in
the kit instructions. Floor protection guidelines, as listed on
Figure 3.2 must also be followed.
Thefactorybuiltchimneymust belistedperUL127(US)
andmeettypeHTrequirementsofUL103(US).Factory
BuiltreplacechimneystestedtoUL127-98maybe,atthe
replacemanufacturersoption,testedtothesamecriteria
asUL103HTrequirements.Ifthechimneyisnotlistedas
meetingHTrequirements,orifthefactorybuiltreplacewas
tested prior to 1998, a full height listed chimney liner must be
installedfromtheapplianceuecollartothechimneytop.
Liner must meet high temperature (2100° F) per UL1777
(US).Thelinermustbesecurelyattachedtoboththeue
collar and the chimney cap. To prevent room air passage to
thechimney cavity of thereplace,sealthe damper area
aroundthechimneylinerwithberglassbatting.
Note: If the Harman® P42i Pellet Insert is installed into
a factory built wood burning replace, the label (Part
#160-1246) to the right MUST be attached to the altered
replace. This label is included in the Manufactured
replace installation kit.
Additionally, the rebox oor of the Zero Clearance
Wood Fireplace may be removed down to the outer
metal shell of the replace if kit 1-00-574305 is used. The
kit includes installation instructions and all materials
needed to remove the rebox oor and still maintain
a safe, compliant installation. Be certain to contact
local code enforcement o󰀩cials before beginning any
modications, as they may not be reversible in many
cases.
Figure 4.5
OPTIONAL HOPPER CONFIGURATIONS FOR SMALLER FIREPLACE
OPENINGS:
The Harman® P42i-TC Pellet Insert can be factory built with shorter hopper
congurations.
Thestandardrequiresa24"opening.Part#1-90-584240
Option1:Requiresa20"openingheight.Part#1-90-584200
Keep in mind the hopper capacities will decrease with the optional heights.
20"
24"
IN CANADA: This replace insert must be installed with a continuous
chimney liner of a minimum 4" diameter extending from the insert to
the top of the chimney. The chimney liner must conform to the Class 3
requirementsofCAN/ULC-S635,StandardforLiningSystemsforExisting
Masonry or Factory Built Chimneys and Vents, or CAN/ULC-S640,
StandardforLiningSystemsforNewMasonryChimneys.
THIS FIREPLACE HAS BEEN ALTERED
TO ACCOMMODATE AN INSERT
AND SHOULD BE INSPECTED BY A
QUALIFIED PERSON PRIOR TO RE-USE
AS A CONVENTIONAL FIREPLACE.
CE FOYER À ÉTÉ MODIFIÉ AFIN D'ÊTRE
UTILISÉ AVEC UNE UNITÉ
ENCASTRABLE ET DEVRAIT ÊTRE
INSPECTÉ PAR UNE PERSONNE
QUALIFIÉE AVANT D'ÊTRE RÉUTILISÉ
COMME UN FOYER CONVENTIONNEL.
160-1246B
