Harman® • P42i Owner’s Manual • 2023 -___ • 03/2319 8742-900A
Service Parts
P42i-TC
Beginning Manufacturing Date: May 2023
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model number
and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
1 Mounting Frame Assembly 1-10-584031A
Roller hardware 4 sets 1-00-02243 Y
2 All Thread .500-13 x 12, Frame Jacking Qty 2 req 3-31-00949
Jack Plate Qty 2 req 1-10-574099W
3 Pipe Stub for 4 in. Flex/PL w/gasket 1-00-574034 Y
4 Pipe Stub Plate Gasket 3-44-574045 Y
5 Docking Gasket Silicone 3-44-06108 Y
6 Thermister Probe (ESP Probe) 3-20-00844
Y
7 Gasket, Hopper Top 20 ft 1-00-375501 Y
Gasket, Hopper Throat 3-44-677185
Y
8 Control Board 1-00-05372
Y
9 Control Board Mounting Plate 1-10-584012A
10 Dierential Switch 3-20-6866 Y
Silicone Tubing, 1/8” 5 Ft 1-00-5113574 Y
11 Hinge Set (4 pc), Side Panel 2 Sets SRV8742-7890
12 Surround, Standard 1-00-742667-1
Surround Hardware Pack SRV8000-042
13 Side Panel Left SRV8742-103L
14 Line Filter Mounting Bracket 1-00-584034
Line Filter 3-20-803744 Y
15 Combustion Cover Latch Assembly 1-00-574080
16 Medallion Holder 1-10-574098W Y
17 Cast Center Medallion 3-00-584027 Y
18 Burn Pot Weldment
See following page
19 Ash Pan 1-10-574007A
Y
20 Cast Top / Hopper Lid Assembly
See following page
21 Door Assembly
See following page
22 Cast Bottom Ashlip SRV8742-018
Door Magnet and Hardware (1 set) Qty 4 req SRV8787-020
23 Combustion Cover 1-10-574087A
24 Hinge Plate Qty 2 req 3-00-674047
25 Side Panel Right SRV8742-103R
26 Spring Latches with hardware Set of 2 1-00-00927 Y
27 Fan Blade
Commonly required
for Combustion Blower
replacement
1-10-574500A Y
Blower Mounting Screws (5 Sets) 1-00-832150
28 Combustion Blower 1-00-02275 Y
Additional service parts on following page.
To Next Page
