Harman Soundcraft Ui12 - Managing Shows and Snapshots; Channel Safes for Snapshot Recall

Ui12, Ui16 User Manual
8.0: SHOWS & SNAPSHOTS
SHOWS & SNAPSHOTS
8.0: SHOWS & SNAPSHOTS
A SHOW is a collection of SNAPSHOTS. A SNAPSHOT is a record of every setting on the console.
You can save and recall snapshots and shows via the Ui control software - Phone or Tablet.
The SHOWS & SNAPSHOTS page is accessible in the tablet software from the SETTINGS page OR by
tapping/clicking the LED display in the top navigation bar (which displays the name of the currently load-
ed snapshot). The quick key to the snapshots pop-up is [8]. You can also assign an F1 or F2 key (top of
Master Channel) to update the current snapshot or create a new one. In the phone software, simply tap the
disk icon or assign the SlideOut F1 key to a snapshot function.
