Service Parts
TL2.6 w/Legs
Beginning Manufacturing Date: Sept 2011
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Damper Frame Assemby W/Damper 1-10-250109A Y
Damper adjuster with hardware 1-00-250153
Damper gasket 30 ft 1-00-00888 Y
Damper Shaft Retainers & Hardware Set of 2 1-00-249145 Y
Damper, Only 1-10-249107
Gasket, 1" single Ply Tape 10 Ft 1-00-88100 Y
2
Firedome Plus Combustion Package 3-40-358110 Y
Gasket, brick air Pkg of 4 3-44-2500202-4 Y
3
Rear brick clips with hardware Pkg of 2 1-00-249135
5
Wooden handle for damper w/hardware Pkg of 2 1-00-00249 Y
6
Damper handle, painted 3-50-00500S Y
7
Damper shaft bushing plates w/hardware Inner & outer 1-00-856061 Y
8
Damper rod weldment 1-10-856011W Y
9
Left side panel, painted 2-00-857019B Y
10
Top Load door Lift Arm w/Knob Post 008850439 1-10-08722 Y
11
Wood Handle w/Hardware Post 008850439 1-00-06228
12 Top Load Door, Painted w/Gasket & Hardware
Pre 008850439 1-10-856509A
Post 008850439 1-10-856009A Y
Bottom Hinge Set of 2 1-00-856084
Hinge Spacer Qty 2 req 2-00-40021L
Top Load Door Gasket 5 Ft 1-00-10050 Y
Wood Handle, Pkg of 3 Pre 008850439 3-40-08746-3
13
Inlet brick 3-40-358112 Y
14
Brick Air Plate Set of 2 1-00-358118 Y
15
Side & rear rebrick 6 pc set 1-00-857047 Y
16
Combustion shoe brick 3-40-00100 Y
17
Ash grate 2-00-857052B Y
18
Ash door asy, painted with handles 1-10-857036A
Ash door latch only Qty 2 req 3-00-249149
Ash door gasket 5 ft 1-00-10000 Y
Ash door hinge with hardware Set of 2 1-00-857050
Ash door roller with hardware Set of 2 1-00-06904
Ash Door Wood Handle Pkg of 3 3-40-08746-3
19
Andiron with hardware and extensions 1-00-856010 Y
Additonal service parts on following page
