Harman TL 2.6 - Dimensions and Clearances; Appliance Dimensions

9
Save These Instructions
TL2.6 Woodburning Stove
Dry Seasoned Wood Only!3-90-08570
A. Appliance Dimensions
The Harman TL2.6 meets the U.S. Environmental Protection
Agency’s emission limits for wood heaters sold after July 1,
1990.
Section 4 - Dimensions and Clearances
22.2"

28.6"

Centered
Outside
Air Kit
9.29"

Outside
Air Kit
7.28"

27.47"

29.48"

Pedestal
Legs

23.9"

34.8"

36.8"

32.7"

34.7"

Pedestal
Legs
Pedestal
Legs

Weight ...................................... 525 lbs
Flue Size ..................................... 6 inch
Log Length Recommended ..........................18"
Average Emission .....................3.7 Grams Per Hr.
Outside Air Size ............................4.5 Inch I.D.
