Service Parts
TL2.6 w/Legs
Beginning Manufacturing Date: Sept 2011
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
18
Front load door asy, painted with glass 1-10-06920A
Ball Spring Bracket 2-00-06714
Cast Door, Painted 4-00-06920P
Door gasket 30 ft 1-00-00888 Y
Door latch, painted w/hdwr & handle 1-00-249119 Y
Glass clips Set of 4 2-00-05202-4 Y
Glass gasket 15 ft 1-00-2312 Y
Glass only 3-40-06932 Y
Latch plate, roller & hardware 1-00-06903
19
Air slide rod bracket with hardware 1-00-856008 Y
20
Air control weldment 1-10-856004W Y
21
Air slide 1-10-856003W Y
22
Shoe brick gasket 3-44-06951 Y
23
Queen Ann Leg, painted w/Hardware Qty 4 req 1-00-7000551 Y
24
Right side panel, painted 2-00-857021B Y
25
Heat shield mounting plate, painted 2-00-856026B
26
Ash pan 1-10-857037A Y
27
Rear heat shield, painted with hardware 1-00-857024 Y
28 Flue collar Weldment, Painted W/Gasket & Hardware
Pre 008850219 1-10-857038W Y
Post 008850219 1-10-857001W Y
29
Flue Opening Cover 1-00-857023
Blower Blockoff 1-00-856019
Brick 12 x 6 x1 1/4 3-40-86125 Y
Brick Insulation Qty 2 req 3-40-857054 Y
Brick retainers with hardware - Side Set of 2 1-00-06945 Y
Cast Weld on Hinge Qty 2 req 3-00-773813
Combustion Package Cap 2-00-358150B
Distribution Blower 7000-537
Power cord 3-20-06652 Y
Snap Disc Control 3-20-408412 Y
Top Vent Cover 1-10-857014
Touch Up Paint
Pre 008850474 3-42-1990
Post 008850474 3-42-19905
Ashlip Trim Brushed Stainless 3-43-4722386-7
Door Trim Brushed Stainless 3-43-856015-7
Additonal service parts on following page
