Harman TLC 2000 Installation & Operating Manual

TLC 2000 Coal Stove
13
Installation
DO NOT INSTALL IN A SLEEPING ROOM
Assembly
Blower(Optional)
Bolt the blower to the bottom rear of the stove with four
1/4-20 bolts. Tighten the bolts, but do not overtighten.
The power cord for the blower must be connected to a
grounded outlet, and may not be routed above, under, over
or around the stove itself.
Blower Variable
Speed knob
TopAirGrill(Optional)
The top air grill must be installed before the chimney con-
nector is installed.
To install simply place the top air grill over the ue out let
and position as shown at left. It is held in place by gravity.
The top air grill is a decorative option that does not add or
subtract from the performance of the stove.
Top Air Grill
