Harmonic HLP 4800 - Rear Panel Description

Chapter 2 Overview HLP 4800 Chassis
© 2009 Harmonic Inc. 13 HLP 4800, Version 1.0, Rev A
Figure 2-1: Front panel HLP 4800
2.1.2 Rear Panel Description
Figure 2-2 on page 13 shows the HLP 4800 rear panel features and locations.
Figure 2-2: Rear panel, HLP 4800
HNC 4800 Controller Display
Five carrier slots for up to ten modules
Provides status of plug-in modules
using a 40-character display
Five push-
button keys:
- ESC
- SET
- Down
- Up
- Enter
Dual power supplies
Ground jack
RJ-11 (reserved for future use)
Alarm relay
Dual ground lug 10-32 UNC
+24v DC backup
