© 2009 Harmonic Inc. 18 HLP 4800, Version 1.0, Rev A
Appendix A
Technical Specifications
A.1 HLP 4800 Technical specifications:
Physical
Power Requirements
Electrical
Environmental
User Interface:
Rear Panel
Dimensions 19” W x 5.25” H x 13” D
48.3 cm W x 13.3 cm H x 33.02 cm D
Weight
(without modules)
17.25 lbs
7.84 kg
Mounting 19” EIA rack, 3 RU spaces
Back-up Input Voltage +24 VDC
Backplane Current Capacity 11 Amps max.
Operating Temperature Range +32
º to +122º F / 0º to +50º C
Storage Temperature Range -40
º to +85º C / -40º to +185º F
Relative Humidity Maximum 95% non-condensing
Alarm activated relay contact
+24 VDC backup
Grounding nut
