Chapter 3
Installing the HLP 4800 Platform
This chapter provides the information necessary to install the HLP 4800. Please read all
instructions before beginning installation.
This chapter describes:
How to receive and inspect the HLP 4800
How to mount the HLP 4800 platform
To install the HNC 4800 controller see the HNC 4800 User’s Guide.
To install and power the CPS4800 power supply see the CPS 4800 User’s Guide.
After you have successfully installed the HNC 4800 controller and the CPS 4800 power
supply, you can access the user interfaces, as described in the HNC 4800 User’s Guide.
CAUTION: To protect yourself from potential injury and to protect the equipment from further damage,
do not perform any operational tests if the equipment appears to be damaged.
CAUTION: Before removing equipment from its antistatic bag, touch a ground point for several
seconds. A suitable ground point is an unpainted part of the chassis of a grounded piece of equipment.
3.1 Tools and Accessories
The following tools are necessary for installation, and are not included with the HLP 4800:
#2 Phillips-head screwdriver
#1 flat-bladed screwdriver
3.2 Receiving and Inspecting
As you unpack your unit, inspect the shipping container and equipment for damage. Save the
shipping material for future use. If the container or the equipment is damaged, notify both the
freight carrier and Harmonic. See Maintenance and Troubleshooting on page 17 for contact
information.
3.3 Mounting the Unit in the Rack
The HLP 4800 occupies three rack-unit spaces in an EIA standard 19-inch rack. Follow these
steps to mount the unit in the rack:
1. Mark the exact position in the rack where you want to install the unit.
2. Prepare the four mounting screws and #2 Phillips screwdriver.
3. Use four mounting screws to attach the mounting brackets on the HLP 4800 rack ears to
the rack.
