Harmony Optyma Harnessed - Page 26

26
❶
❷
2. Face the rear of the child
restraint and remove
the harness straps and
shoulder straps from the
splier plates ❶.
3. Pull the harness straps out
of their respecve slots
in the backrest ❷ and
remove shoulder pads.
4. Connue to thread the
harness strap through
the plasc base and completely
remove it ❸.
5. Store complete harness system for
future use.
6. To remove the crotch buckle,
please see secon “Removing the
crotch buckle“.
7. Pull the up-front harness
adjustment strap as far as
it will go. This will lock the
splier plate into the base
of the seat ❹.
8. Roll strap ghtly,
secure roll with an
elasc band and
store rolled strap
under the fabric
seat pad in the
opening of the up-front adjuster.
To reinstall, reverse the above steps.
❹
❸
