8.0 Dual Alternate Output Module
Alternate Output B Source Selections
Monitor source selection for the Alternate Output B output are Mix Bus 1, Mix Bus 2, Aux 1-4
and an External input provided via XLR connectors on the console rear.
Alternate Output B Controls
The Alternate Output B level knob controls the Alternate Output B output level from mute to
unity gain. MONO combines the left and right monitor sources and MUTE mutes the Alternate
Output B output.
Alternate Output A Source Selections
Monitor source selection for the Alternate Output A output are Mix Bus 1, Mix Bus 2, Aux 1-4
and an External input provided via XLR connectors on the console rear.
Alternate Output A Controls
The Alternate Output A level knob controls the Alternate Output A output level from mute to
unity gain. MONO combines the left and right monitor sources and MUTE mutes the Alternate
Output A output.
Talkback Section
Allows direct talk back to either Alternate Output A or Alternate Output B outputs.
950mx analog console overview v1.5 Page 12
