11.0 Power Supply Specifications
The 950mx includes the Harrison L-159 power supply and associated power cable. The included power
cable is 10 feet (3.05 meters) in length. Custom lengths are available for additional cost.
Input Specifications* minimum nominal maximum
Input Voltages (AC) 100 VAC 87 VAC 100 VAC 110 VAC
120 VAC 104 VAC 120 VAC 132 VAC
220 VAC 191 VAC 220 VAC 242 VAC
240 VAC 209 VAC 240 VAC 264 VAC
Input Frequency 47Hz 63Hz
*Derate output current 10% for 50Hz operation. Input voltage tolerance for 230 VAC operation is +15%, -10%.
Output Specifications minimum nominal maximum
Output Adjustment -5% +5%
Efficiency 55%
Ripple and Noise 5.0 mVpk-pk
Output Voltages +15 VDC
-15 VDC
+48VDC
13.00" 1.16"
6.12"
5.50"
15.32"
14.14"
2.08" 10.00"
