13.0 Module Jumper Settings
Mono Mic/Line Module Jumper Settings
Function Settings
J2 Aux 1 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J3 Aux 2 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J4 Aux 3 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J5 Aux 4 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J6 Logic Options Jump 1-2 for Control Room mute on fader
open.
Jump 3-4 for Studio A mute on fader open.
Jump 5-6 for Studio B mute on fader open.
Stereo Line Module Jumper Settings
Function Settings
J2 Aux 1 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J3 Aux 2 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J4 Aux 3 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J5 Aux 4 Pre/Post Jump 1-2 for post-fader. Jump 2-3 for pre-
fader.
J6 Logic Options Jump 1-2 for Control Room mute on fader
open.
Jump 3-4 for Studio A mute on fader open.
Jump 5-6 for Studio B mute on fader open.
Program Module Jumper Settings
Function Settings
J2 PGM 1L Insert Jump 1-2 to bypass insert. Jump 2-3 to
activate insert.
J3 PGM 1R Insert Jump 1-2 to bypass insert. Jump 2-3 to
activate insert.
J4 PGM 2L Insert Jump 1-2 to bypass insert. Jump 2-3 to
activate insert.
J5 PGM 2R Insert Jump 1-2 to bypass insert. Jump 2-3 to
activate insert.
Control Room Module Jumper Settings
Function Settings
J2 Mute on Talk Jump 1-2 to mute on talk (default).
