HART HLCS01 - Battery Pack Installation and Removal; Chain Oil System Maintenance

13 – English
OPERATION
NOTICE:
Before each use, inspect the entire product
fordamaged,missing,orloosepartssuchas
screws,nuts,bolts,caps,etc.Tightensecurely
allfastenersandcapsanddonotoperatethis
productuntilallmissingordamagedpartsare
replaced.Pleasecontactcustomerserviceor
anauthorizedservicecenterforassistance.
APPLICATIONS
Youmay use thisproduct forthe following
purposes:
Limbingandpruningbranchesfromtrees
Felling small trees
Bucking the fallen tree into shorter lengths
TO INSTALL/REMOVE BATTERY PACK
See Figure 5.
WARNING:
Always remove battery pack from your tool
when you are assembling parts, making
adjustments, cleaning, carrying, transporting
orwhennotinuse.Removingbatterypackwill
prevent accidental starting that could cause
seriouspersonalinjury.
NOTE: Toavoidseriouspersonalinjury,always
removethebatterypackandkeephandsclearof
thelock-outbuttonwhencarryingortransporting
the tool.
To install:
Placethebatterypackinyourchainsaw.Align
raisedribonbatterypackwithgrooveinchain
saw’sbatteryport.
WARNING:
Makesurethelatchonthebatterypacksnaps
inplaceandthebatterypackisfullyseatedand
secureinthepowerheadbatteryportbefore
beginningoperation. Failuretosecurelyseat
thebatterypackcouldcausethebatterypack
tofallout,resultinginseriouspersonalinjury.
To remove:
Locate latch on bottomof battery packand
depressto release thebattery packfrom the
chain saw.
BATTERY
PACK
LATCH
BATTERY
PORT
FIG. 5
FIG. 6
NOTICE:
Whenplacingbatterypackinyourchainsaw,
besureraisedribonbatterypackalignswith
grooveinchainsaw’sbatteryportandlatches
snapinplaceproperly.Improperassemblyof
battery pack can cause damage to internal
components.
Forcompletecharginginstructions,seetheoper-
ator’smanualsforyourbatterypackandcharger.
CHAIN OIL SYSTEM
See Figure 6.
NOTICE:
Removebatterypackfromunit.Filloiltankwith
barandchainlubricant(notprovided)before
starting the chain saw. Failure to lubricate the
chain will cause damage to the bar and chain.
Use barand chainlubricant (not provided).
Thatis formulatedto performover awide
temperaturerangewithnodilutionrequired.
