MAINTENANCE
WARNING:
Toavoidseriouspersonalinjury,alwaysremovethe
batterypackfromtheproductwhencleaning
orperforminganymaintenance.
WARNING:
Alwaysweareyeprotectionwithsideshields
markedtocomplywithANSIZ87.1aswellas
headandhearingprotectionwhenoperating
thisequipment. Failure to do so could result in
objects being thrown into your eyes and other
possibleseriousinjuries.
WARNING:
Whenservicing,useonlyidenticalreplacement
parts. Use of any other parts can create a
hazardorcauseproductdamage.
WARNING:
Neverusewateroranyliquidstocleanorrinse
offyourproductanddonotexposetheproduct
to rain or wet conditions. Store indoors in a dry
area.Corrosiveliquids,water,andchemicals
canentertheproduct’selectroniccomponents
and/orbatterycompartmentanddamageelec-
tronic components and/or the battery pack,
which can result in a short circuit, increased risk
offire,andseriouspersonalinjury.Removeany
buildupofdirtanddebrisbywipingtheproduct
clean with a dry cloth occasionally.
NOTICE:
Periodically inspect the entire product for
damaged, missing, or loose parts such as
screws,nuts,bolts,caps,etc.Tightensecurely
allfastenersandcapsanddonotoperatethis
productuntilallmissingordamagedpartsare
replaced.Pleasecontactcustomerserviceor
anauthorizedservicecenterforassistance.
GENERAL MAINTENANCE
Avoidusingsolventswhencleaningplasticparts.
Mostplastics aresusceptible todamage from
varioustypesofcommercialsolventsandmaybe
damagedbytheiruse.Usecleanclothstoremove
dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating
oils, etc., come in contact with plastic
parts. Chemicals can damage, weaken or
destroyplastic which could result in serious
personalinjury.
REPLACING BAR AND CHAIN
See Figures 24 - 30.
WARNING:
Removethebatterypackfromthechainsaw
andmakesurethechainhas stoppedbefore
you do any work on the saw. Failure to do so
mayresultinaccidentalstartingandpossible
serious injury.
WARNING:
To avoid serious personal injury, read and
understand all the safety instructions in this
section.
BAR MOUNTING
NUTS
FIG. 24
BAR
BAR MOUNTING
NUTS
CHAIN
COVER
CHAIN
FIG. 25
MOUNTING
SURFACE
