HART HLCS01 User Manual

22 – English
WARNING:
Never touch or adjust the chain while the
motorisrunning.Thesawchainisverysharp;
alwayswearprotectivegloveswhenperforming
maintenance to the chain to avoid possible
serious lacerations.
CAUTION:
Alwaysweargloveswhenhandlingthebarand
chain;thesecomponentsaresharpandmay
contain burrs.
NOTE: Whenreplacingtheguidebarandchain,
alwaysusethespecifiedbarandchainlistedin
the Bar and Chain Combinations section later
in this manual.
Removethebatterypackbeforeyoudoany
work on the chain saw.
Removethebarmountingnutsusingthecom-
binationwrenchprovided.
Removethechaincover.
Removethebarandchainfromthemounting
surface.
Removetheoldchainfromthebar.
Layout the newsaw chain ina loopand
straighten any kinks. The cutters should face
in the direction of chain rotation. If they face
backwards,turntheloopover.
Placethechaindrivelinksintothebargroove
as shown.
NOTE: Make certain of direction of chain.
Positionthechainsothereisaloopattheback
of the bar.
Holdthechaininpositiononthebarandplace
thelooparoundthesprocket.
Fit the bar flush against the mounting surface
so that the bar studs are in the long slot of the
bar.
Replacethechaincoverensuringthatthead-
justingpininthechaincoverisinthebarchain
tensioningpinholeandthatbothbarstudsare
securelyintheirrespectiveholesinthechain
cover.
NOTE: Theadjustingpinmayneedtobeslight-
lyrepositionedwiththechaintensioningscrew
sothatitisalignedwiththepositionofthebar
chaintensioningpinhole.
MAINTENANCE
CHAIN DRIVE LINKS
CUTTERS
CHAIN ROTATION
BAR
GROOVE
CHAIN DRIVE
LINKS
CHAIN
TENSION PIN
HOLE
ADJUSTING
PIN
BAR STUDS
BAR
MOUNTING
NUTS
CHAIN
COVER
FIG. 26
FIG. 27
FIG. 28
