HART HPCS01 User Manual

10 - English
POCKET CUTTING
See Figure 20, page 14.
WARNING:
Always adjust bevel setting to zero before making a
pocketcut.Attemptingapocketcutatanyothersetting
canresultinlossofcontrolofthesawpossiblycausing
seriousinjury.
Removethebatterypack.
 Adjustthebevelsettingtozero.
 Setthebladetothecorrectbladedepthsetting.
 Swingthelowerbladeguardupusingthelowerblade
guardhandle.
NOTE: Alwaysraisethelowerbladeguardwiththehandle
toavoidseriousinjury.
 Holdthelowerbladeguardbythehandle.
WARNING:
Neverextendyourfingerswhileholdingthelowerblade
guard handle. Extending your fingers could result in
contactwiththeblade,causingseriousinjury.`
OPERATION
ADJUSTING 0° BEVEL STOP
 Removethebatterypack.
 Loosenbevellockknob.
 Loosenhexnutsecuringadjustingscrew.
 Turnadjustingscrewandadjustbaseuntilsquarewith
sawblade.
 Tightenhexnutandbevellockknobsecurely.
WARNING:
Attempting a bevel cut without having the bevel
adjustmentknobsecurelytightenedcanresultinserious
injury.
WARNING:
Topreventaccidentalstartingthatcouldcauseserious
personalinjury,alwaysremovethebatterypackfromthe
productwhenmakingadjustments.
0° BEVEL STOP
See Figure 21, page 14.
Thesawhasa0°bevelstopthathasbeenfactoryadjusted
toassure0°angleofthesawbladeplatewhenmaking90°
cuts.
CHECKING 0° BEVEL STOP
 Removethebatterypack.
 Placethesawinanupsidedownpositiononaworkbench.
 Checkthesquarenessofthesawbladeplatetothebase
ofthesawusingacarpenter’ssquare.
ADJUSTMENTS
 Restthefrontofthebaseflatagainsttheworkpiecewith
therearofthehandleraisedsothebladedoesnottouch
theworkpiece.
 Startthesawandletthebladereachfullspeed.
 Guidethesawintotheworkpieceandmakethecut.
WARNING:
Alwayscutinaforwarddirectionwhenpocketcutting.
Cuttinginthereversedirectioncouldcausethesawto
climbupontheworkpieceandbacktowardyou.
 Releasethetriggerandallowthebladetocometoa
completestop.
 Liftthesawfromtheworkpiece.
 Clearcornersoutwithahandsaworsabresaw.
WARNING:
Never tie the lower blade guard in a raised position.
Leavingthebladeexposedcouldleadtoseriousinjury.
