HART HPCS25 User Manual

6 - English
 Removethebatterypackfromthesaw.
 Removethebladewrench(6mmhexkey)fromthestorage
area.
 Depressthespindlelockbuttonandremovetheblade
screwandouterbladewasher.
NOTE: Turnthebladescrewcounterclockwisetoremove.
NOTICE:
Topreventdamagetothespindleorspindlelock,always
allowmotortocometoacompletestopbeforeengaging
spindlelock.
NOTE: Donotrunthecircularsawwithspindlelockengaged.
 Wipeadropofoilontotheinnerbladewasherandouter
bladewasherwheretheycontacttheblade.
WARNING:
Ifinnerbladewasherhasbeenremoved,replaceitbefore
placingbladeonspindle.Failuretodosocouldcausean
accidentsincebladewillnottightenproperly.
 Fitthesawbladeinsidethelowerbladeguardandonto
thespindle.
NOTE:Thesawteethpointupwardatthefrontofthesaw.
 Replacetheouterbladewasher.
 Depressthespindlelockbutton,thenreplacetheblade
screw.Tighten the blade screw securely by turning it
clockwise.
 Returnthebladewrenchtothestoragearea.
NOTE:Neveruseabladethatistoothicktoallowtheouter
bladewashertoengagewiththeflatsonthespindle.
REMOVING THE BLADE
See Figure 2, page 12.
 Removethebatterypackfromthesaw.
 Removethebladewrenchfromthestoragearea.
 Position the saw as shown, depress the spindle lock
buttonand remove the blade screwby turning it
counterclockwise.
 Removetheouterbladewasher.
 Removetheblade.
UNPACKING
Thisproductrequiresassembly.
 Carefullyremovetheproductandanyaccessoriesfrom
thebox.Allitemslistedinthe Includessectionmustbe
includedatthetimeofpurchase.
WARNING:
Items in this Assembly section are not assembled to
theproductbythemanufacturerandrequirecustomer
installation. Use of a product that may have been
improperlyassembledcouldresultinseriouspersonal
injury.
 If anyparts are damaged or missing, please call
1-800-776-5191forassistance.
WARNING:
Ifanypartsaredamagedormissingdonotoperatethis
productuntilthepartsarereplaced.Useofthisproduct
withdamagedormissingpartscouldresultinserious
personalinjury.
WARNING:
Do not attempt to modify this product or create
accessoriesnotrecommendedforusewiththisproduct.
Anysuchalterationormodificationismisuseandcould
result in a hazardous condition leading to possible
seriouspersonalinjury.
WARNING:
Topreventaccidentalstartingthatcouldcauseserious
personalinjury,alwaysremovethebatterypackfromthe
productwhenassemblingparts.
ATTACHING THE BLADE
See Figure 1, page 12.
WARNING:
A7-1/4in.bladeisthemaximumbladecapacityofthe
saw.Neveruseabladethatistoothicktoallowouter
bladewashertoengagewiththeflatsonthespindle.
Largerbladeswillcomeincontactwiththebladeguard,
while thicker blades will prevent blade screw from
securing blade on spindle. Either of these situations
couldresultinaseriousaccident.
ASSEMBLY
FEATURES
PRODUCT SPECIFICATIONS
BladeDiameter ....................................................... 7-1/4in.
BladeArbor ............................................................... 5/8in.
CuttingDepthat45º ............................................... 1-3/4in.
CuttingDepthat0º ................................................. 2-3/8in.
CuttingSpeed .....................................................4,000/min
