Hartzell HC-E4 3 Series - Section 3

Propeller Owner’s Manual
147
INSTALLATION AND REMOVAL
61-00-47
Page 3-1
Rev. 17 Sep/20
INSTALLATION AND REMOVAL - CONTENTS
1. Tools, Consumables, and Expendables ................................. 3-5
A. General ............................................................................. 3-5
B. Tooling ............................................................................... 3-5
C. Consumables .................................................................... 3-5
D. Expendables ..................................................................... 3-5
2. Pre-Installation ........................................................................ 3-6
A. Inspection of Shipping Package ........................................ 3-6
B. Uncrating ........................................................................... 3-6
C. Inspection after Shipment ................................................. 3-6
D. Reassembly of a Propeller Disassembled for Shipment ... 3-6
3. Propeller Mounting Hardware and Torque Information ......... 3-11
A. Propeller Mounting Hardware ......................................... 3-11
B. Torque Information .......................................................... 3-11
4. Propeller Assembly Installation ............................................. 3-12
A. Precautions ..................................................................... 3-12
B. Installing HC-E(4,5)( )-3( ) except HC-E5P-3 and
HC-E5W-3 Propellers on the Aircraft Engine .................. 3-15
C. Installing the HC-E5P-3 Propeller
on the Aircraft Engine ...................................................... 3-23
D. Installing the HC-E5W-3( ) Propeller
on the Aircraft Engine ...................................................... 3-26
E. Installing the HC-E(4,5)N-5KL Propeller
on the Aircraft Engine ...................................................... 3-34
F. Installing HC-E5A-2 Propeller on the Aircraft Engine ...... 3-39
G. Installing HC-E5B-5A Propeller on the Aircraft Engine ... 3-45
5. Spinner Dome Installation .................................................... 3-51
A. General ........................................................................... 3-51
B. For Propeller Model HC-E5A-2, Installing the
Striker Plates (Pilatus part) ............................................. 3-51
C. For Propeller Model HC-E5A-2, Measuring the
Resistances .................................................................... 3-53
D. Installing the Spinner Dome ............................................ 3-53
