61-00-47
REVISION HIGHLIGHTS
Page 1
Rev. 17 Sep/20
Propeller Owner's Manual
147
REVISION 17 HIGHLIGHTS
Revision 17, dated September 2020, incorporates the following:
Front matter (Cover, Revision Highlights, etc.), has been revised to
match this revision.
Minor language/format changes and renumbering, if applicable are
marked with a revision bar, but are not listed below.
• DESCRIPTION AND OPERATION
• Added Figure 2-6.1, "HC-E5W-3( ) Series Propeller"
• Revised the section, "Description of Propellers and Systems"
• Revised Table 2-1, "Propeller Model Designations"
• INSTALLATION AND REMOVAL
• Revised the section, "Tools, Consumables, and
Expendables"
• Revised Table 3-1, "Propeller/Engine Flange O-rings and
Mounting Hardware"
• Revised Table 3-2, "Torque Table"
• Revised Figure 3-4, "Tool for Decompressing HC-E(4,5)( )-3( )
Series External Beta System"
• Revised the section, "Installing HC-E(4,5)( )-3( ) except
HC-E5P-3 and HC-E5W-3 Propellers on the Aircraft Engine"
• Added the section, "Installing the HC-E5W-3 Propeller on the
Aircraft Engine"
• Added Figure 3-8, "Hub-to-Spacer O-ring Location in the
Spacer"
• Added Figure 3-9, "Installing the HC-E5W-3( ) Propeller on
Engine Flange"
• Added Figure 3-10, "Installing the Washer on the Mounting
Stud"
• Revised the section, "Spinner Dome Installation"
To Next Page
