Harvia Xenio CX004WIFI User Manual

8
EN
Xenio WiFi -Control panel (CX001WIFI) x
MyHarvia mobile application (x)
Compatible devices
CX170-U1-15-XW
CX170-U3-15-XW
CX30-U1-U3-XW
CX45-U1-U3-XW
CX30C-U1-XW
CX30C-U3-XW
Temperature adjustment range 40 - 90 °C / 104 - 194 °F x (x) x (x)
Humidity adjustment range 20-80 rH x (x)
On-time 1h x x
Control of lighting ON / OFF -button x (x) x (x)
Automation: ON when heater turns on (x) (x)
Control of fan ON / OFF -button x (x) x (x)
Automation: ON when heater turns off (x) (x)
Timed start adjustment range 0-12h x x
- For one heating
- Based on calendar
(x) (x)
Week clock - Max. 8 programs (x) (x)
Safety device option Safety switch (optional) x x
Time zone selection Yes (x) (x)
Daylight saving selection Yes (x) (x)
Xenio WiFi -Control panel (CX001WIFI)
Dimensions (mm) 85 x 24 x 110
Connection 4-pin: +12VDC, GND, RS485 A+B
Supply 12-24VDC
Power consumption Peak 2W, average 600mW
WiFi frequency band 2,4 GHz
Storage conditions -25-70°C / -4 - 158 °F
Ambient 0-70°C / 32 - 158 °F
Air humidity Max 99%, non-condensing
Dimensions for flush mounting hole 67 x 96 mm / 2.6 x 3.8 inch
Harvia Xenio WiFi CX004WIFI Remote Kit Compatibility
Please check serial number from the
product. If the serial number in the
product is bigger than presented in the
table, it is Xenio WiFi and MyHarvia
compatible.
Harvia Finland Oy
Name:
Xenio CX170 U1-15
Item No:
CX1502401-15
ver.HA157.XX
6417659019262
SN PU: xxxxxxxxxx
SN UI: xxxxxxxxxx
DD.MM.YYYY
Item numbers Serial number
CX30-U1-U3
CX45-U1-U3
CX30C-U1
CX30C-U3
CX1502083-15
SN PU: 2034xxxxxx (For example: SN PU: 2034000001)
CX1502401-15 SN PU: 2036xxxxxx (For example: SN PU: 2036000001)
TECHNICAL DATA
Table 1a. Technical data, Xenio WiFi control panel / MyHarvia mobile application
