27. Technical Data
The Como, certifi ed in compliance with DIN-EN 13240 : 2001 + A2 2004 and Art. 15 a
B-VG (Austria), can only be operated when the fi re box is closed; more than one device
can be connected to the chimney.
VKF-No.: 18009; Inspection Report No. (AT): FSPS-Wa 1756-A
The following data applies to the chimney characteristics in accordance with EN 13384-1 / 2:
Depending on the insulation of the building, the nominal thermal output of 7 kW indicated
on 25 - 95 m² (subject to change)
Dimensions: Height Width Depth
Stove 117,5 cm 62 cm 57 cm
Fire box 27,5 cm 36 cm 33 cm
Weight (ceramic / soapstone): 215 / 271 kg
Fire Box Opening: 1106 cm²
Flue pipe diameter: 15 cm
Pipe diameter of Hase ventilation system* 10 cm
* For separate air supply in low-energy houses and insuffi cient combustion air supply in the
room where the stove is installed
Front view Side view
Top view
Dimensions in cm
Combustion Values Wood Briquettes
Nominal Thermal Output 7 7 kW
Waste Gas Mass Flow Rate 7 7 g/s
Waste Gas Outlet Temp. 300 300 ˚C
Min. Supply Pressure at Nominal Thermal Output 11 11 Pa
CO content at 13% O2
0,07 0,07
Vol%
Effi ciency 82 81 %
Particulate 36 35 mg/Nm³
Stove height: 117,5
Height for rear installation: 99
Height for top installation: 112
Height for the inst. of Hase air system: 17
17,5
62
57
