9
One control can be used for several winders, however, either independ-
ently or together. In this case the code must be transferred to each
winder individually.
To programme an IR Remote control code with a winder proceed as follows:
1. Attach winder (with batteries) to the camera.
2. Select RC mode on the winder.
3. Aim the IR Remote Control at one of the infrared sensors on the
winder.
4. Depress both winder and IR Remote Control release buttons at
the same time for 3–4 seconds.
A winder can be re-programmed at any time to receive a new code from
another IR Remote control simply by repeating the programming pro-
cedure with the new control.
Restrictions
With the winder attached, the following Hasselblad accessories cannot
be used:
Cable release, Flashgun bracket 1, Quick-focusing handle
Certain studio flash units or slave units when set in the
IR trigger mode might immediately be fired by the signal
from the IR Remote control and consequently will not be
in synchronization with the shutter on the camera. In this
case either make tests or use a conventional flash synchro-
nization cable to connect the camera with the flash unit.
Release cord 9
e 3m long Release cord (3044123)—(optional extra)—is connected
into the socket on the underside of the winder. It provides the same
function as the manual release button. When activated, the winder car-
ries out its operation according to the pre-selected mode (S, C, and M).
e socket is a conventional 3.5 mm jack plug socket (female) and so
any switched cord with a conventional 3.5 mm triple-pole jack plug
(male) may be used. See diagram for correct wiring conguration.
