5
Hasselblad Winder CW
The Winder CW (3044105) is a compact, ergonomically designed
unit providing not only a motor drive facility but also a comfort-
able and robust grip for the 503CW and 503CXi cameras.
It features single exposure, continuous exposure, multi-exposure
and remote control modes. Remote control is achieved either by
an electronic cord release or by a handy infrared transmitter – the
Hasselblad IR Remote control (3044113), both providing consider-
able freedom. The IR Remote Control additionally oers a remote
mode-choice facility.
As the winder is set close to the camera body, it produces stabil-
ity and balance for optimum hand held efficiency – the perfect
requirement for vertical 6x4.5 shots. A removable strap oers extra
security and is adjustable to suit personal requirements.
A special feature is the SAI (Self Adjusting Interface) that senses not
only whether the camera is wound but also the unique mechanical
status of the camera body and attached equipment, such as a lm
magazine, for example.
The figures beside the small headings refer to the relevant illus-
trations.
Parts and components 1
1. Mode selector index
2. Release button
3. Mode selector
4. Front IR sensor
5. Winder coupling
6. Bayonet mount
7. Winder retaining slot
8. Winder catch
9. Release cord socket
10. Camera release lever
11. Lower strap lug
ENG
