Hatco HDW-2 - Electrical Rating Chart - HDW-xN Models; Electrical Rating Chart - HDW-xB Models

Form No. HDWM_CN-0817
6
English
SPECIFICATIONS
Electrical Rating Chart — HDW-xN Models
Model Voltage Watts Amps PlugConguration Shipping Weight
HDW-1N 100 450 4.5 JIS C 8303 15 A, 125 V 38 kg (83 lbs.)
220 450 2.0 CEE 7/7 Schuko 38 kg (83 lbs.)
240 450 1.9 BS-1363 38 kg (83 lbs.)
220–230 450–492 2.0–2.1 CEE 7/7 Schuko 38 kg (83 lbs.)
230–240 413–450 1.8–1.9 BS-1363 38 kg (83 lbs.)
HDW-2N 100 900 9.0 JIS C 8303 15 A, 125 V 76 kg (168 lbs.)
220 900 4.1 CEE 7/7 Schuko 76 kg (168 lbs.)
240 900 3.8 BS-1363 76 kg (168 lbs.)
220–230 900–984 4.1–4.3 CEE 7/7 Schuko 76 kg (168 lbs.)
230–240 826–900 3.6–3.8 BS-1363 76 kg (168 lbs.)
HDW-3N 100 1350 13.5 JIS C 8303 15 A, 125 V 105 kg (232 lbs.)
220 1350 6.1 CEE 7/7 Schuko 105 kg (232 lbs.)
240 1350 5.6 BS-1363 105 kg (232 lbs.)
220–230 1350–1476 6.1–6.4 CEE 7/7 Schuko 105 kg (232 lbs.)
230–240 1239–1350 5.4–5.6 BS-1363 105 kg (232 lbs.)
Electrical Rating Chart — HDW-xB Models
Model Voltage Watts Amps PlugConguration Shipping Weight
HDW-1B 220 450 2.0 Hardwired w/ Conduit 40 kg (88 lbs.)
240 450 1.9 Hardwired w/ Conduit 40 kg (88 lbs.)
220–230 450–492 2.0–2.1 Hardwired w/ Conduit 40 kg (88 lbs.)
230–240 413–450 1.8–1.9 Hardwired w/ Conduit 40 kg (88 lbs.)
HDW-2B 220 900 4.1 Hardwired w/ Conduit 72 kg (159 lbs.)
240 900 3.8 Hardwired w/ Conduit 72 kg (159 lbs.)
220–230 900–984 4.1–4.3 Hardwired w/ Conduit 72 kg (159 lbs.)
230–240 826–900 3.6–3.8 Hardwired w/ Conduit 72 kg (159 lbs.)
HDW-3B 220 1350 6.1 Hardwired w/ Conduit 105 kg (232 lbs.)
240 1350 5.6 Hardwired w/ Conduit 105 kg (232 lbs.)
220–230 1350–1476 6.1–6.4 Hardwired w/ Conduit 105 kg (232 lbs.)
230–240 1239–1350 5.4–5.6 Hardwired w/ Conduit 105 kg (232 lbs.)
NOTE: Shipping weight includes packaging.
NOTE: Shipping weight includes packaging.
